Transparent OLED Touch Signage
$10,667.00
30EW5TP-A
Transparent OLED Touch Signage
$10,667.00
Key Features
All Specs
- Brightness (Typ.) : 200 / 600 nit (APL 100% / 25%, Without Glass)
- Transparency : 37% (Set)
- Bezel : 7.9 mm (T/R/L), 114.7 mm (B)
- Interface : HDMI / DP / USB 2.0 / Touch USB / RS232C / RJ45 / IR / Audio
- P-Cap Touch, Tempered Front Glass (3T)
Compare
3 Year Limited Warranty
Buy with confidence knowing your product is backed by a 3 year limited warranty.
Free Delivery
Enjoy free delivery on your business orders.
Free Returns
Shop with confidence. Free returns within 14 days of delivery.
Features and Specs
Vivid Colors
Featuring self-lighting pixels, the display maintains vivid colors and high contrast ratio even when the display becomes transparent. It brings content to life from wide viewing angles, and the content blends into its surroundings seamlessly and naturally
Intuitive P-Cap Touch
By adding P-Cap touch sensor film to the display, the utilization possibilities expand to various industries where customer interaction services are demanding. Users could enjoy its fascinating content using their fingertips with no lag.
LG SuperSign™ Solutions
SuperSign™ is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign™ Cloud, so discover and enjoy the version that best fits you.
High Transparency
LG Transparent OLED signage seamlessly and naturally blends into it surroundings thanks to its high transparency. These see-through digital displays turn static signage areas into open and interactive spaces.
Protective Tempered Glass
Touching a display directly can cause damage or scratches. This transparent OLED display has a tempered front glass that protects the display from external impacts.
Enhanced Spatial Versatility
Experience the extraordinary with the state-of-the-art LG Transparent OLED Signage, which breaks down the barriers between the screen and surrounding environment, seamlessly connecting different spaces and people
Software Features
Gapless Playback
Yes
Picture-by-Picture (PBP)
No
Control Manager
Yes
SI Server Setting
Yes
Setting Data Cloning
Yes
Status Mailing
Yes
Auto Set ID
No
Scan Inversion
No
Backlight Sync
No
ISM Method
Yes
Group Manager
Yes
Booting Logo Image
No
Network Ready
No
RS-232C Sync
Yes
W/B Setting by Grayscale
No
webRTC (Real Time Communication)
No
Video Tag
Yes (4)
PM mode
Yes
Picture-in-Picture (PIP)
No
Local Network Sync
Yes
Screen Rotation
Yes
Smart Energy Saving
No
Tile Mode Setting
No
External Input Rotation
No
No Signal Image
No
SNMP
Yes
Brightness Compensation
No
Local Contents Scheduling
Yes
HDMI-CEC
Yes
USB Plug & Play
Yes
OPS Compatibility
OPS Power Built-in
No
OPS Compatible
No
Hospitality Features
Pro:Idiom®
No
Wake on LAN
Yes
Electrical
Power Consumption (Max.)
86W
Power Supply
100-240 Vac, 50/60 Hz
Power Consumption (Power Off)
0.5W
Power Type
Built-in Power
PoE Type
N/A
PoE Power Class
N/A
Power Consumption (Display Power Management - DPM)
0.5W
Power Consumption (Smart Energy Saving - 70%)
Yes
BTU Heat Generation (Max.)
294 BTU
BTU Heat Generation (Typ.)
154 BTU
Power Consumption (Typ.)
45W
Mechanical
Bezel Color
Black
Bezel Width
T/R/L: 3.5 mm, B: 23 mm
Bezel Width (On Bezel)
Not Available
Bezel Width (Off Bezel)
Not Available
Tilt (Face Down)
No
Tilt (Face Up)
No
Weight
198.6 lbs / 90.1 kg
Weight Signage Box
N/A
Weight with Stand
N/A
Shipping Weight
270.9 lbs / 122.9 kg
Dimensions (W x H x D)
98.8 x 44.2 x 3.7 in / 2,510.6 x 1,123.1 x 93.6 mm
Dimensions with Stand (W x H x D)
No
Dimensions with Pemnut (W x H x D)
No
Dimensions Signage Box (W x H x D)
No
Shipping Dimensions (W x H x D)
105.0 x 11.0 x 51.4 in / 2,668 x 280 x 1,305 mm
Conformal Coating (Power Board)
Yes
Handle
Yes
VESA™ Standard Mount Interface
No
Overlay Touch Compatibility
No
Smart Calibration
No
Power Protection
No
Direct Sunlight
No
Protective Glass
Thickness
4 mm
Degree of Protection
No
Tempered / Chemical Strengthening
Thermal Tempering
Anti-Reflective
Yes
Anti-Reflective Coating
5%
Anti-Reflective Film
No
Infrared - Resistance (IR)
No
Shatter-Proof
Yes
Heat Dissipation
No
Heater
No
Noise Level
No
Audio/Sound
Built-in Speakers
No
Hardware Features
Local Key Operation
Yes
Built-in Microphone
No
Built-in Camera
No
Pixel Sensor
No
Temperature Sensor
Yes
Auto Brightness Sensor
No
Built-in Cooling Fan
No
Acceleration (Gyro) Sensor
No
Current Sensor
No
BLU Sensor
No
Power Indicator
No
Proximity Sensor
No
Humidity Sensor
No
Features
Crestron Certified Compatibility
No
Beacon
No
Play Via URL
No
Cisco Certified Compatibility
No
Failover
Yes
System
Operating System (OS)
webOS™ 7.5
Processor
No
Graphics
No
Storage
No
Internal Memory
16 GB (eMMC)
Touch Panel
Available Object Size for Touch
Greater than 8 mm
Response Time (PC Win10, Education Mode)
No
Touch Response Time (G to G)
Less than 100 ms
Writing Height
No
Accuracy (Typ.)
2 mm
Interface
USB 2.0
Active Pen Interface
No
Multi Touch Point (Max.)
10 Points
Protection Glass Transmission
85%
Protective Glass Thickness
3.0 T (Anti-reflection / Anti-finger Print)
Operating System Support
Windows 10/11
Connectivity
HDMI In
Yes (x1) HDCP 2.2/1.4
IR In (3.5 mm)
Yes
IR In (3.5 mm)
Yes
DVI-D In
No
RGB In
No
Audio In (3.5 mm)
No
DisplayPort In
Yes (x1) HDCP 1.3
RS-232C In (3.5 mm 4-pin)
Yes (x1)
RS-232C In (D-sub 9-pin)
No
RJ45 (LAN) In
Yes (x1)
USB Type-A In
Yes (x1) USB 2.0
USB Type-C In
No
Power In (DC From External PWR Box)
No
Power Loop In
No
HDMI Out
No
DisplayPort Out
Yes (x1)
Audio Out (3.5 mm)
Yes (x1)
Touch USB
Yes (x1) USB 2.0 Type B
IR Out
Sharing RS-232C Out
RJ45 (LAN) Out
Yes (x1)
RS-232C Out (3.5 mm)
Yes (x1)
RS-232C Out (D-sub 9-pin)
No
Power Loop Out
No
External Speaker Out (3.5 mm)
No
Bluetooth
No
Daisy Chain
Not Available
Built-in Wi-Fi
No
Warranty & Other
Warranty
3 Year Limited
Onscreen Display Languages
Arabic, Chinese (Original), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Italian, Japanese, Korean, Norwegian, Polski, Portuguese (Brazil), Portuguese (Europe), Russian, Simplified Chinese, Spanish, Swedish, Türkçe
Basic Accessories (included)
Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS-232C Gender, MCX / Harness Cables (3 m × 4 ea / 3 m × 2 ea for Connection between Panel and Signage Box), HDMI Cable (3 m), Micro to A Type USB Cable (3 m, for Connection between Touch and Signage Box), A to B Type USB Cable (Touch Out), Screw (M4 × L22, 12 ea / M4 Nut 12 ea / M3 × L5.5 (Silver), M3 × L5.5 (Black) 8 ea / Shield Cover Assy, Rubber Damper 4 ea, Touch Cable Holder 2 ea, MCX Cable Holder 2 ea
Environmental Conditions
Operation Humidity
10% to 80%
Operation Temperature (Portrait)
N/A
Operation Temperature
32°F to 104°F / 0°C to 40°C
Regulatory & Certifications
UL Certification
No
U.S. ePEAT (Environmental)
No
FCC (Regulatory)
EMC Class A
IP Rating (Solid / Liquid Ingress)
No
CE Marking (Regulatory)
Yes
ISTA6 (Packaging)
No
ERP (Environmental)
Yes
Energy Star (Environmental)
No
Smart Features
Screen Share
No
LG Software Compatible
SuperSign™ CMS
Yes
SuperSign™ Media Editor
No
SuperSign™ Control+
Yes
SuperSign™ WB
No
SuperSign™ Cloud
Yes
Mobile CMS
Yes
ConnectedCare™
Yes
Panel
Screen Size (Inches)
30”
Panel Technology
OLED
Backlight Type
OLED
Aspect Ratio
16:9
Native Resolution
1366 x 768 (HD)
Refresh Rate
120 Hz
Brightness (Typ.)
200 / 600 nits (APL 100% / 25%, without Glass)
Brightness (Max.)
Not Available
Brightness (Min.)
Not Available
Contrast Ratio
200000:1
Dynamic Contrast Ratio
No
Color Gamut
BT709 110%
Color Depth (Number of Colors)
10 bit, 1.07 Billion Colors
Viewing Angle (H x V)
178° x 178°
Response Time (G to G)
1 ms
Moving Picture Response Time
8 ms
Surface Treatment (Haze)
3%
Surface Treatment (Anti Glare)
No
Surface Treatment (Hard Coating)
5H
Reflectance (Typ.)
No
Operation Hours (Hours per Day / Days per Week)
18/7 (Moving Content Only)
Lifetime
Up to 30,000 Hrs
Orientation
Portrait / Landscape
Transparency
37% (Set)
QWP (Quarter Wave Plate)
No
¹ This feature may have a restriction depending on the TV models.
