55" class (54.6" diagonal) IPS Direct LED Super Narrow Bezel Video Wall
DISCONTINUED
55WV70BS-B
55" class (54.6" diagonal) IPS Direct LED Super Narrow Bezel Video Wall
Key Features
All Specs
- IPS- IN PLANE SWITCHING
- Super IPS 178° Viewing Angle
- ULTRA NARROW BEZEL WIDTH
- AUTO CALIBRATION
Compare
Specs & Resources
OUTPUT (Rear)
Digital
DVI-D(1)
Audio
External speaker
Analog
Component(1), Composite(1), RGB(1) (Shared with D-Sub)
External Control
RS232C
INPUT (Rear)
Audio
PC/AV/Component Audio In(1)
HDTV Formats
Component : 720p/1080i/1080p HDMI :720P/1080i/1080p
External Control
RS232C(1), RJ45(1)
Digital
HDMI(1), DVI(1), Display Port(1) with HDCP for all input
USB
USB(1)
Analog
Component(1), AV(1), RGB(1) (Shared with D-Sub)
AUDIO
Sound Mode
Standard, Music, Cinema, Sports, Game
Audio Power
20W (10W x 2)
Clear Voice II
Yes
Speaker on/off
Yes
Balance
Yes
SOFTWARE COMPATIBILITY
SuperSign Elite-w lite Editing, Scheduling, Distribution & Play, Control
Yes
ENVIRONMENT CONDITIONS
Operation Temperature
0°C~40°C
Operation Humidity
10%~80%
SPECIAL FEATURES
Smart Energy Saving
Yes, Off/ Minimum/ Medium/ Maximum/ Screen Off/ Auto
Key Lock
Yes
ISM Method
Yes
Input Label
Yes
Temperature Sensor
Yes
File Play with USB
Yes
Brightness/Contrast /Backlight
Yes
Position/Size
Yes
Auto Config/Phase
Yes
Auto Power/Source Memory
Yes
PIP/PBP
Yes
Multi-media Playback
Yes
Tile mode @ Natural mode
Yes, Up to 15 x 15
Shine Out Panel
No
CABINET
Bezel Width
3.4mm (left/top) / 1.9mm(right/bottom)
VESA™ Standard Mount Interface
600mm x 400mm
Monitor Dimensions
47.8” x 27.0” x 3.9” (W x H x D) (head only)
Monitor Weight
73.6 lbs. (head only)
Packed Weight
93.5 lbs.
Carton Dimensions
55.1” x 31.7” x 13.0” (W x H x D)
WARRANTY
WARRANTY
3-Year Limited Warranty (Parts/Labor/Backlight)
MEDIA PLAYER COMPATIBILITY
External Media Player Attatchable
Yes
UPC
UPC
7 19192 19085 6
VIDEO (PC)
Max Input Resolution
1920 X 1080@ 60Hz (RGB,HDMI/DVI-D)
Recommended Resolution
1920 X 1080@ 60Hz (RGB,HDMI/DVI-D)
V-Scanning Frequency
56Hz ~ 75Hz (RGB), 56Hz~63Hz (HDMI/DVI-D
Pixel Frequency
148.5 MHz (RGB, HDMI/DVI-D)
Picture Mode
Vivid, Standard, Cinema, Sports, Game
Color Temperature
Warm, Medium, Cool
H-Scanning Frequency
30 ~ 68 kHz (RGB, HDMI/DVI-D)
POWER
Power Supply
100–240V~, 50/60Hz
Power Consumption-DPM
1W
Power Consumption-Power Off
0.5W
Power Consumption-Normal (Typ.)
160W
Power Consumption-Smart Energy Saving On
90W
STANDARD CERTIFICATIONS
Safety
UL / cUL / CB / TUV / KC
EMC
FCC / CE / KCC
ErP / Energy Star
Yes / Yes (EPA 5.1)
PANEL
Panel Size
55" class (54.64" measured diagonally)
Contrast Ratio
1,400:1
Response Time
9ms (G to G), 8ms (G to G, WOT)
Brightness
500 cd/m^2
Panel Technology
IPS
Aspect Ratio
16:9
Native Resolution
1920 x 1080 (FHD)
Dynamic CR
500,000 : 1
Surface Treatment
Hard coating(3H), Anti-reflection treatment of the front polarizer (Reflectance < 2%)
Orientation
Portrait & Landscape
Color Depth
1.06 Billion
Viewing Angle
178°/178°
Lifetime
60,000 Hrs
Color Gamut
72%
Tni
110°
Pixels(H x V x 3)
6,220,800
