Advanced Edge Adjustment (12 Point Warping) 4K UHD resolution with 8.3 million discrete pixels projected by XPR (Expanded Pixel Resolution) video processing
Audio/Sound
Built-in Speakers
Yes 10W (5W+5W Stereo)
Features
Edge Blending
No
Crestron RoomView™
No
Tile Mode
No
Auto Screen Adjustment
No
IP Control
Yes
Software Features
Picture-by-Picture (PBP)
No
Compatibility One:Quick Share
No
Picture-in-Picture (PIP)
No
Wireless Content Share
Yes (with iOS, Adroid via TV Plus App, with DLNA supporting device)
USB Plug & Play
No
System
Operation System (OS)
N/A
Internal Memory
N/A
Connectivity
HDMI In
Yes (x2) 2.0 HDCP 2.2
HDMI ARC Support
No
Audio In (3.5 mm)
No
DisplayPort In
No
RS-232C In (3.5 mm 4-pin)
Yes (x1)
RJ45 (LAN) In
1 (HDBaseT)
USB Type-A In
Yes (x2) USB 2.0
Simplink (HDMI-CEC)
No
HID
Yes (Keyboard/Mouse/GamePad Connection Thru USB)
HDMI Out
No
Audio Out (3.5 mm)
Yes (x1)
RS-232C Out (3.5 mm 4-pin)
No
Bluetooth Sound Out
Yes
Bluetooth AV Sync Adjustment
Yes
Bluetooth
Yes
Built-in Wi-Fi
No
Discontinued Specs
Specs
{"tv_inputs_outputs_spec":{"spec_attributes":[{"spec_code":"tv_audio_out_inputs_outputs_spec","spec_name":"Audio out","spec_value":"1 (Φ3.5)"},{"spec_code":"tv_hdmi_inputs_outputs_spec","spec_name":"HDMI™","spec_value":"2"},{"spec_code":"tv_rj45_inputs_outputs_spec","spec_name":"RJ45","spec_value":"1 (HDBaseT)"},{"spec_code":"tv_ip_control_inputs_outputs_spec","spec_name":"IP Control","spec_value":"Yes"},{"spec_code":"tv_usb_type_a_inputs_outputs_spec","spec_name":"USB Type A","spec_value":"2 (USB2.0)"},{"spec_code":"tv_rs_232c_inputs_outputs_spec","spec_name":"RS-232C","spec_value":"Yes"},{"spec_code":"tv_hid_inputs_outputs_spec","spec_name":"HID","spec_value":"Yes (Keyboard\/Mouse\/GamePad Connection Thru USB)"}],"spec_group_name":"INPUTS\/OUTPUTS"},"tv_power_spec":{"spec_attributes":[{"spec_code":"tv_power_consumption_power_spec","spec_name":"Power Consumption","spec_value":"380W"},{"spec_code":"tv_standby_mode_power_spec","spec_name":"Standby Mode","spec_value":"<0.5W"},{"spec_code":"tv_power_supply_voltage_hz_power_spec","spec_name":"Power Supply (Voltage\/Hz)","spec_value":"100V \u2013 240V @ 50~60 Hz (PSU Built-in)"}],"spec_group_name":"POWER"},"tv_connectivity_wireless_spec":{"spec_attributes":[{"spec_code":"tv_bluetooth_with_speaker_connectivity_wireless_spec","spec_name":"Bluetooth (with Speaker)","spec_value":"Yes"},{"spec_code":"tv_screen_share_connectivity_wireless_spec","spec_name":"Screen Share","spec_value":"Yes (with Miracast supporting device)"},{"spec_code":"tv_wireless_contents_share_connectivity_wireless_spec","spec_name":"Wireless Contents Share","spec_value":"Yes (with iOS, Adroid via TV Plus App, with DLNA supporting device)"}],"spec_group_name":"CONNECTIVITY\/WIRELESS"},"tv_warranty_upc_spec":{"spec_attributes":[{"spec_code":"tv_limited_warranty_warranty_upc_spec","spec_name":"Limited Warranty","spec_value":"3 Years"},{"spec_code":"tv_upc_warranty_upc_spec","spec_name":"UPC","spec_value":"719192641204"}],"spec_group_name":"WARRANTY\/UPC"},"tv_dimensions_weight_spec":{"spec_attributes":[{"spec_code":"tv_product_wxhxd_dimensions_weight_spec","spec_name":"Product (WxHxD)","spec_value":"Without Lens : 14.6\" x 6.1\" x 11.4\", 14.6\" x 5.7\" x 11.4\" (Without Leg), With Lens : 14.6\" x 6.1\" x 12.8\", 14.6\" x 5.7\" x 12.8\" (Without Leg)"},{"spec_code":"tv_shipping_dimensions_wxhxd_dimensions_weight_spec","spec_name":"Shipping Dimensions (WxHxD)","spec_value":"22.8\" x 10.7\" x 17.4\""},{"spec_code":"tv_weight_dimensions_weight_spec","spec_name":"Weight","spec_value":"21.4 lbs"},{"spec_code":"tv_shipping_weight_dimensions_weight_spec","spec_name":"Shipping Weight","spec_value":"25.4 lbs"}],"spec_group_name":"DIMENSIONS\/WEIGHT"},"tv_audio_spec":{"spec_attributes":[{"spec_code":"tv_bluetooth_sound_out_audio_spec","spec_name":"Bluetooth sound out","spec_value":"Yes"},{"spec_code":"tv_built_in_speakers_audio_spec","spec_name":"Built-in Speakers","spec_value":"10W (5W+5W Stereo)"},{"spec_code":"tv_bluetooth_av_sync_adjustment_audio_spec","spec_name":"Bluetooth AV Sync Adjustment","spec_value":"Yes"}],"spec_group_name":"AUDIO"},"tv_projection_system_spec":{"spec_attributes":[{"spec_code":"tv_display_type_projection_system_spec","spec_name":"Display Type","spec_value":"DLP"},{"spec_code":"tv_native_resolution_projection_system_spec","spec_name":"Native Resolution","spec_value":"4K UHD (3840 x 2160)*"},{"spec_code":"tv_screen_size_projection_system_spec","spec_name":"Screen Size","spec_value":"40\" ~ 300\""},{"spec_code":"tv_projection_image_projection_system_spec","spec_name":"Projection Image","spec_value":"100\"@9.4~15.2ft"},{"spec_code":"tv_aspect_ratio_projection_system_spec","spec_name":"Aspect Ratio","spec_value":"16:9\/Original\/4:3\/Vertical Zoom | All-Direction Zoom"},{"spec_code":"tv_brightness_projection_system_spec","spec_name":"Brightness","spec_value":"Up to 5000 ANSI Lumens**"},{"spec_code":"tv_contrast_ratio_projection_system_spec","spec_name":"Contrast Ratio","spec_value":"3,000,000:1"},{"spec_code":"tv_lamp_type_projection_system_spec","spec_name":"Lamp Type","spec_value":"Laser (LD + P\/W)"},{"spec_code":"tv_lamp_life_projection_system_spec","spec_name":"Lamp Life","spec_value":"Up to 20,000 hrs"},{"spec_code":"tv_hdcp_projection_system_spec","spec_name":"HDCP","spec_value":"HDCP 2.2"},{"spec_code":"tv_trumotion_projection_system_spec","spec_name":"Trumotion","spec_value":"Yes"},{"spec_code":"tv_hdr_projection_system_spec","spec_name":"HDR","spec_value":"HDR10"},{"spec_code":"tv_digital_keystone_correction_projection_system_spec","spec_name":"Digital Keystone Correction","spec_value":"Advanced Edge Adjustment (12 Point Warping)"},{"spec_code":"tv_zoom_projection_system_spec","spec_name":"Zoom","spec_value":"1.6x"},{"spec_code":"tv_star_projection_system_spec","spec_name":"*","spec_value":"4K UHD resolution with 8.3 million discrete pixels projected by XPR (Expanded Pixel Resolution) video processing"},{"spec_code":"tv_star2_projection_system_spec","spec_name":"**","spec_value":"The Brightness is based on the perceived brightness equivalent to the brightness of lamp projector"},{"spec_code":"tv_lens_shift_projection_system_spec","spec_name":"Lens Shift","spec_value":"Horiz ± 20% | Vert ± 50%"},{"spec_code":"tv_noise_typical_projection_system_spec","spec_name":"Noise (Typical)","spec_value":"26\/27\/29 dB (A)"}],"spec_group_name":"PROJECTION SYSTEM"},"tv_lg_smart_tv_spec":{"spec_attributes":[{"spec_code":"tv_web_browser_lg_smart_tv_spec","spec_name":"Web Browser","spec_value":"Yes"}],"spec_group_name":"LG SMART TV"},"tv_accessories_manual_spec":{"spec_attributes":[{"spec_code":"tv_remote_control_accessories_manual_spec","spec_name":"Remote Control","spec_value":"1 Standard (Battery included)"},{"spec_code":"tv_manual_accessories_manual_spec","spec_name":"Manual","spec_value":"Simple Book"},{"spec_code":"tv_power_cord_accessories_manual_spec","spec_name":"Power Cord","spec_value":"Yes"}],"spec_group_name":"ACCESSORIES\/MANUAL"}}
Warranty & Other
Warranty
3 Year Limited
UPC
7 19192 64120 4
Basic Accessories (included)
Remote Control 1 (Batteries included), Manual, Power Cord
Advanced Edge Adjustment (12 Point Warping) 4K UHD resolution with 8.3 million discrete pixels projected by XPR (Expanded Pixel Resolution) video processing
