55” XS4J-B IPS Full HD Window Facing Display with High Visibility, Wide Operating Temperature Range, & Smart Brightness Control
DISCONTINUED
55XS4J-B
55” XS4J-B IPS Full HD Window Facing Display with High Visibility, Wide Operating Temperature Range, & Smart Brightness Control
Key Features
All Specs
- Full HD (1,920 x 1,080) IPS Display
- 4,000nits High Brightness
- Slim Bezel (T,B / R,L): 12.0 / 9.9 mm
- webOS™ Smart Platform version 4.1
- Built-in Wi-Fi
- Web-based Monitoring Solution
Compare
Features and Specs
Rain or Shine Brightness
With a brightness of 4,000 nits, XS4J delivers images and videos that attract public attention, making it the ultimate display for outdoor visibility. This display uses Quarter Wave Panels (QWP) to ensure clear visibility, even through polarized lenses.*
*Max. 4,000 nits, Typ. 3,200 nits (Based on LG internal test conducted in February, 2021).
*Max. 4,000 nits, Typ. 3,200 nits (Based on LG internal test conducted in February, 2021).
High Performance with webOS™
Quad Core SoC (System-on-Chip) can execute several tasks at the same time without a separate media player. In addition, webOS 4.1 platform enhances user convenience with intuitive UI and simple app development tools.
Slim Bezel Design
With its elegant slim bezel design, the XS4J attracts attention, helps enhance the visual impact of the content displayed, and elevates the store’s overall ambiance.
Smart Brightness Control
The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased for better visibility, while it is decreased in darkness for efficient power management.*
*The smart brightness control feature is based on an LG internal test conducted in February 2021.
*The smart brightness control feature is based on an LG internal test conducted in February 2021.
High Energy Efficiency
XS4J is energy efficient, allowing for an efficient total cost management while showing content with 4,000 nits of high brightness.*
*Typical power consumption of XS4J is 345W(49XS4J), 375W(55XS4J) at ‘On Mode’ based on LG internal test conducted in February, 2021. The figure may differ depending on the actual environment.
*Typical power consumption of XS4J is 345W(49XS4J), 375W(55XS4J) at ‘On Mode’ based on LG internal test conducted in February, 2021. The figure may differ depending on the actual environment.
Wide Operating Temperature
The XS4J can operate at temperatures as low as 32°F (0°C) and as high as 104°F (40°C)*, making it suitable for virtually any storefront.
*Based on LG internal test conducted in February, 2021.
*Based on LG internal test conducted in February, 2021.
Easy Wireless Distribution & Updates
The XS4J features built-in Wi-Fi, making it easy to distribute content wirelessly and update Firmware.
Web Monitoring
This web-based monitoring solution is user-friendly and enables the user to have full access virtually anywhere, any time from their mobile phone while having access to historical data. It allows the user to monitor the unit, make adjustments, and control the unit remotely in real-time.
Software Features
Gapless Playback
Yes
Picture-by-Picture (PBP)
Yes (2)
Control Manager
Yes
SI Server Setting
Yes
Setting Data Cloning
Yes
Status Mailing
Yes
Auto Set ID
Yes
Scan Inversion
No
Backlight Sync
Yes
ISM Method
Yes
Group Manager
Yes
Booting Logo Image
Yes
Network Ready
Yes
RS-232C Sync
Yes
W/B Setting by Grayscale
No
webRTC (Real Time Communication)
Yes
Video Tag
Yes (4 | Ext. Source (x2), Video (x4))
PM mode
No
Picture-in-Picture (PIP)
Yes
Local Network Sync
Yes
Screen Rotation
Yes
Smart Energy Saving
No
Tile Mode Setting
Yes (Max. 15 x 15)
External Input Rotation
Yes
No Signal Image
Yes
SNMP
Yes
Brightness Compensation
No
Local Contents Scheduling
Yes
HDMI-CEC
Yes
USB Plug & Play
Yes
OPS Compatibility
OPS Power Built-in
No
OPS Compatible
No
Hospitality Features
Pro:Idiom®
Yes
Wake on LAN
Yes
Electrical
Power Consumption (Max.)
400W
Power Supply
100-240 Vac, 50/60 Hz
Power Consumption (Power Off)
Less than 0.5W
Power Type
Built-in Power
PoE Type
N/A
PoE Power Class
N/A
Power Consumption (Display Power Management - DPM)
Less than 0.5W
Power Consumption (Smart Energy Saving - 70%)
145W
BTU Heat Generation (Max.)
1,365 BTU
BTU Heat Generation (Typ.)
1,280 BTU
Power Consumption (Typ.)
375W
Mechanical
Bezel Color
Black
Bezel Width
T: 12.0 mm, R/L: 9.9 mm, B: 12 mm
Bezel Width (On Bezel)
Not Available
Bezel Width (Off Bezel)
Not Available
Tilt (Face Down)
No
Tilt (Face Up)
No
Weight
57.3 lbs / 26.0 kg
Weight Signage Box
N/A
Weight with Stand
N/A
Shipping Weight
68.8 lbs / 31.2 kg
Dimensions (W x H x D)
48.6 x 27.9 x 3.4 in / 1,235.5 x 709.4 x 85.4 mm
Dimensions with Stand (W x H x D)
N/A
Dimensions with Pemnut (W x H x D)
N/A
Dimensions Signage Box (W x H x D)
N/A
Shipping Dimensions (W x H x D)
53.5 x 9.1 x 33.2 in / 1,360 x 231 x 844 mm
Conformal Coating (Power Board)
Yes
Handle
Yes
VESA™ Standard Mount Interface
600 x 400 mm
Overlay Touch Compatibility
No
Smart Calibration
No
Power Protection
No
Direct Sunlight
No
Protective Glass
Thickness
No
Degree of Protection
No
Tempered / Chemical Strengthening
No
Anti-Reflective
No
Anti-Reflective Coating
No
Anti-Reflective Film
No
Infrared - Resistance (IR)
No
Shatter-Proof
No
Heat Dissipation
No
Heater
No
Noise Level
No
Audio/Sound
Built-in Speakers
No
Hardware Features
Local Key Operation
Yes
Built-in Microphone
No
Built-in Camera
No
Pixel Sensor
No
Temperature Sensor
Yes
Auto Brightness Sensor
Yes
Built-in Cooling Fan
Yes
Acceleration (Gyro) Sensor
Yes
Current Sensor
No
BLU Sensor
N/A
Power Indicator
No
Proximity Sensor
No
Humidity Sensor
N/A
Features
Crestron Certified Compatibility
No
Beacon
Yes
Play Via URL
Yes
Cisco Certified Compatibility
No
Failover
Yes
System
Operating System (OS)
webOS™ 4.1
Processor
No
Graphics
No
Storage
No
Internal Memory
16 GB (eMMC)
Touch Panel
Available Object Size for Touch
No
Response Time (PC Win10, Education Mode)
No
Touch Response Time (G to G)
N/A
Writing Height
No
Accuracy (Typ.)
No
Interface
No
Active Pen Interface
No
Multi Touch Point (Max.)
No
Protection Glass Transmission
No
Protective Glass Thickness
No
Operating System Support
No
Connectivity
HDMI In
Yes (x2) HDCP 2.2/1.4
IR In (3.5 mm)
Yes (x1)
DVI-D In
No
RGB In
No
Audio In (3.5 mm)
No
DisplayPort In
Yes (x1) HDCP 1.3
RS-232C In (3.5 mm 4-pin)
Yes (x1)
RS-232C In (D-sub 9-pin)
No
RJ45 (LAN) In
Yes (x1)
USB Type-A In
Yes (x1) USB 2.0
USB Type-C In
No
Power In (DC From External PWR Box)
No
Power Loop In
No
HDMI Out
No
DisplayPort Out
Yes (x1) input DPDMI
Audio Out (3.5 mm)
No
Touch USB
No
IR Out
No
RJ45 (LAN) Out
No
RS-232C Out (3.5 mm)
Yes (x1)
RS-232C Out (D-sub 9-pin)
No
Power Loop Out
No
External Speaker Out (3.5 mm)
Yes (x1) L/R, 10W+10W
Bluetooth
No
Daisy Chain
No
Built-in Wi-Fi
Yes
Warranty & Other
Assembled In
South Korea
Warranty
3 Year Limited
Onscreen Display Languages
Arab, Chinese (Original), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Italian, Japanese, Korean, Norwegian, Portuguese (Brazil), Portuguese (Europe), Russian, Simplified Chinese, Spanish, Swedish, Türkçe
Optional Accessories
WM-L640V (Landscape wall mount), WM-P640V (Portrait wall mount) ** Stand is not available
UPC
1 95174 01218 5
Basic Accessories (included)
Remote Controller (including battery 2ea), Power Cord, HDMI Cable,Manual (EIG, IG), IR Receiver(w/ Ambient Light Sensor), RS-232C Adapter
Environmental Conditions
Operation Humidity
10% to 80%
Operation Temperature (Portrait)
N/A
Operation Temperature
30°F to 104°F / 0°C to 40°C (w/o Direct Sunlight, Direct Sunlight in Cooling System) 30°F to 86°F (Direct Sunlight)
Regulatory & Certifications
UL Certification
No
U.S. ePEAT (Environmental)
No
FCC (Regulatory)
EMC Class A
IP Rating (Solid / Liquid Ingress)
No
TAA Compliance
Yes
CE Marking (Regulatory)
Yes
ISTA6 (Packaging)
No
ERP (Environmental)
Yes
Energy Star (Environmental)
No
Smart Features
Screen Share
No
LG Software Compatible
SuperSign™ CMS
Yes
SuperSign™ Media Editor
No
SuperSign™ Control+
Yes
SuperSign™ WB
No
SuperSign™ Cloud
No
Mobile CMS
No
ConnectedCare™
Yes
Panel
Screen Size (Inches)
55"
Panel Technology
IPS, M+
Backlight Type
Direct
Aspect Ratio
16:9
Native Resolution
1920 x 1080 (FHD)
Refresh Rate
60 Hz
Brightness (Typ.)
4,000 nits
Brightness (Max.)
Not Available
Brightness (Min.)
3,200 nits
Contrast Ratio
1000:1
Dynamic Contrast Ratio
500000:1
Color Gamut
NTSC 72%
Color Depth (Number of Colors)
16.7 Million Colors, 8 bit
Viewing Angle (H x V)
178° x 178°
Response Time (G to G)
9 ms
Moving Picture Response Time
N/A
Surface Treatment (Haze)
3%
Surface Treatment (Anti Glare)
No
Surface Treatment (Hard Coating)
No
Reflectance (Typ.)
N/A
Operation Hours (Hours per Day / Days per Week)
24/7
Lifetime
Up to 50,000 Hrs
Orientation
Portrait / Landscape
Transparency
No
QWP (Quarter Wave Plate)
Yes
All image simulations are for illustration purposes only.
