Wallpaper OLED Signage
DISCONTINUED
55EJ5D
Wallpaper OLED Signage
Key Features
All Specs
- Brightness : 400 cd/m2 (APL 25%)
- Bezel: 1.2 mm (Off bezel)
- Depth: 3.65 mm (Module)
- Interface: HDMI, DP, RS232C, RJ45, IR In, USB 3.0, USB 2.0
- SuperSign Premium / Link
Compare
Specs & Resources
PHYSICAL SPECIFICATIONS
Weight
Head: 5.5 kg, Signage Box: 5.3 kg, Wall Bracket: 1.8 kg
Bezel Color
Black
Dimensions (W x H x D)
Head: 1,227 x 702.1 x 3.65 mm, Signage Box: 420 x 230 x 75 mm
Bezel Width
1.2, 1.2, 1.2, 1.2 mm (U, B, L, R *Offset bezel)
Dimensions (Carton) (W x H x D)
54.4" x 32.8" x 9.9"
Packed Weight
49.6 lbs
CONNECTIVITY
Input
HDMI, DP
Output
DP, Audio
External Control
RS232C in/out, RJ in/out, IR Receiver, USB 2.0, USB 3.0
ENVIRONMENTAL CONDITIONS
Operation Humidity
10 % to 80 %
Operating Temperature Range
32°F ~ 104°F / 0°C ~ 40°C
SOFTWARE COMPATIBILITY
Control and Monitoring Software
SuperSign Link
Content Management Software
SuperSign Premium
MEDIA PLAYER COMPATIBILITY
External Media Player Attatchable
Yes
OPS Type Compatible
Yes
POWER
Power Type
Built-in Power
Typ.
190 W
Power Off
Less than 0.5 W
Power Supply
100–240V~, 50/60Hz
DPM
Less than 3 W
SPECIAL FEATURES
Yes
Temperature Sensor, Cooling FAN, Source Selection, DPM Select, Energy Saving, Motion Eyecare, File Play with USB, Internal Memory (64 GB), Wi-Fi Dongle Ready, USB Cloning, Contents Scheduling, Local Time Auto Setting, Failover, Mirroring, SoftAP, BEACON, DP daisy chain
STANDARD CERTIFICATION
ErP / Energy Star
Yes / NA
Safety
UL / cUL / CB / TUV / KC
EMC
FCC Class "A" / CE / KCC
PANEL
Surface Treatment
Hard coating (2H), Anti-reflection treatment of the front polarizer (Reflectance typ. 1.0%)
Panel Technology
OLED
Aspect Ratio
16 : 9
Brightness
100/400 cd/m2 (APL 100%/25%) *Average Picture Level
Native Resolution
1,920 x 1,080 (FHD)
Viewing Angle (H x V)
178 x 178
Dynamic CR
100,000:1
Orientation
Landscape & Portrait
Response Time
1 ms (G to G), 8 ms (MPRT)
Screen Size
55” class (54.64” diagonal)
Operation Hours
18 hrs/7 days (Moving video only)
ACCESSORIES
Basic
Remote controller (includes 2 batteries), FPC Extension cable (connection between screen and signage box), Power cord, DP cable, RS-232C cable, RS-232C gender, LAN cable, IR receiver, Manual (ESG, EIG), Wall-mount plate (includes screws), Harness locking cover, Set install guide, Signage box bracket (U-Leg), FPC cable cover
Optional
OPS kit (KT-OPSA)
All image simulations are for illustration purposes only.
