Open-Frame OLED Signage
DISCONTINUED
55EF5C-M2
Open-Frame OLED Signage
Key Features
All Specs
- Brightness: 400 cd/m2 (APL* 25%) * APL: Average Picture Level
- Bezel: 7.2 mm (U/B/R/L, Off-bezel)
- Available in 2,000R for landscape, 1,500R for portrait (Concave & Convex)
- HDMI, DP, RJ45, IR, RS232C, USB, Audio out, Internal memory (64 GB), SuperSign OLED/C
Compare
Specs & Resources
PHYSICAL SPECIFICATIONS
Bezel Width
7.2, 7.2, 7.2, 7.2 mm (U, B, L, R *Off-bezel)
CONNECTIVITY
Input
HDMI, DP
Output
DP, Audio
External Control
RS232C in/out, RJ45 in, IR receiver, LAN out, IR out, USB
ENVIRONMENTAL CONDITIONS
Operation Humidity
10 % to 80 %
Operating Temperature Range
0°C to 40°C
SOFTWARE COMPATIBILITY
SuperSign-c
Yes
SuperSign OLED
Yes
MEDIA PLAYER COMPATIBILITY
External Media Player Attachable
Yes
OPS Type Compatible
Yes
POWER
Power Type
Built-in Power
Power Supply
100-240V~, 50/60Hz
STANDARD CERTIFICATION
ErP / Energy Star
Yes / NA
Safety
UL / cUL / CB / TUV / KC
EMC
FCC Class "A" / CE / KCC
PANEL
Brightness
100/400 cd/m2 (APL 100% / 25%) * Average picture level
Resolution
1,920 x 1,080 (FHD)
Screen Size
55"
ACCESSORIES
Basic
Remote Controller (including battery 2 ea), Power Cord, QSG, Mini HDMI Cable (3M x 2 ea, for connection between head and signage box), Power Harness Cable (3M x 2 ea, for connection between head and signage box), Regulation Book, Phone to RS232C Gender, Jack Cover, Signage Box Mounting Bracket
Optional
OPS Kit (KT-OPSA), Fixed Ceiling Mount Kit (ACC-CF-EH5C), Rotational Ceiling Mount Kit (ACC-CR-EH5C), Wall Mount Kit (ACC-W-EH5C), Stand Kit 1 (ACC-S-EH5C), Stand Kit 2 (ACC-S1-EH5C), Signage Box Cover (ACC-C-EH5C)
