Pro:Centric® SMART Set Top Box
DISCONTINUED
STB-3000
Pro:Centric® SMART Set Top Box
Key Features
All Specs
- Pro:Centric® Smart IPTV Platform
- Embedded Pro:Idiom® decryption for non-Pro:Idiom TV's
- IP Streaming and RF Tuning
- HD Channel Support (up to 1080p)
- Pro:Centric Application Support for non-Pro:Centric TVs
Compare
Specs & Resources
GENERAL SPECIFICATION
Weight (w/o package)
1.1 lbs
Weight (with package)
3.1 lbs
Dimensions
8.7” x 1.1” x 6.9”
ACCESSORIES
Manual/ESG
Simple book
Cable
HDMI, MPI, RS232, AV gender
Adapter
Yes
AUDIO
Optical Sound Sync
YES (SPDIF)
POWER
Voltage, Hz
100V - 240V, 50/ 60 Hz
Stand-by
0.3W↓
Typical (Watts)
15W
INTERFACE (REAR)
LAN Port
Yes
Digital Audio Out (Optical)
Yes
Power
Yes
Tuner
Yes
Display Control 1(4 Pin 3.5mm Jack)
Yes
External IR (3Pin 3.5mm Jack)
Yes
Service (3 Pin 3.5mm Jack)
Yes
AV In (4 Pin 3.5mm Jack)
Yes
HDMI Out
Yes
SPECIAL FEATURES
USB Cloning
Yes
Logical Channel Map
Yes
Pro:Centric Application
Yes
Multi IR Code
Yes
IR Out
Yes (MPIJack/RS232)
Auto Configuration
Yes (EZ-Manager)
Remote Diagnosis
Yes (IP)
Audio Codec
AC3 (Dolby Digital), EAC3, AAC, MPEG, MP3, PCM
Smart Energy Saving (Auto Power Off)
Yes
Pro:Idiom
Yes
Hotel Mode/ PDM /Installer Menu
Yes (Installer Menu)
Video Mute
Yes
Multicast/ Unicast ready
Yes
WiFi Direct
Yes
IP Streaming
Yes (RTSC, HLS, SNMP, UDP/MultiCast, USB Port/Video Streaming support (Smartshare) (※IGMPv3 SSM Support)
Auto Off /Auto Sleep
Yes
DLNA(Movie/Photo/Music)
Yes (Smart Share)
WiDi
Yes
RF (1/2Tuner)
1 Tuner
SI Compatible
YES (MPI protocol/TVLink Tuner Protocol)
Wi-Fi
Yes (Built-in type)
Pro:Centric Smart
Yes
Hybrid Streaming (IP & RF) ※ MultiCast/HTTP Data Carousel
Yes
HCAP (GEM/FLASH/HTML) ※Service Carousel (TLX)
Yes
Application (P:C Smart)
Yes (Commercial CP/Apps)
Miracast (Mobile to TV)
Yes
IR In
Yes (Display Control 1 & 2, External IR Receiver)
BT (Blue Tooth)
Yes (Built-in)
Audio Line Out
Yes (3.5mm, Stereo, Single Ended (GND, L+,R+)
USB
USB 2.0
JPEG
SAP (Soft Access Point)
Yes (Built-in)
REQUIRED LISTING (CERTIFICATION)
Safety
UL
EMC
FCC
ETC
RoHS, cUL, NOM, Energy Star 4.1
VIDEO
Triple XD Engine
Yes
Output Resolution
720p/1080p/1366 x 768
INTERFACE (FRONT)
Display Control 2 (RJ-12)
Yes
MPI
Yes
HDMI (1,2)
Yes
USB (1,2)
Yes
BROADCASTING SYSTEM
Analog
Yes, NTSC
Digital
Yes, ATSC, Clear QAM / VSB
All image simulations are for illustration purposes only.
