65" class (64.53" diagonal) with Integrated Pro:Idiom® and b-LAN

Name: 65" class (64.53" diagonal) with Integrated Pro:Idiom® and b-LAN
Brand: LG Electronics
SKU: 65LY570H
Availability: Discontinued

DISCONTINUED

65LY570H

65" class (64.53" diagonal) with Integrated Pro:Idiom® and b-LAN

Key Features

All Specs

RAISING THE STANDARD OF FINE SERVICE
A TRUE DEDICATION TO MUTUAL SUCCESS
MAXIMIZING THE GUEST EXPERIENCE
LG Pro:Centric® Application

Compare

Specs & Resources

Collapse All

WARRANTY

2-Year Limited Warranty (Parts/Labor)

AUDIO

Clear Voice II

Yes

Sound Mode

Yes, 6 Modes (Standard, News, Music, Cinema, Sport, Game)

Speaker System

2.0 ch

Audio Output

10W + 10W

Optical Sound Sync

Yes

Sound Optimizer

Yes (3 Modes: Normal, Wall-Mount Type, Stand Type)

INTERFACE (Rear)

RF In

1 Rear

AV In

1 Rear

Digital Audio Out

1 Rear (Optical)

HDMI/HDCP Input

1 Rear

External Speaker Out

1 Rear (3.5mm phone jack)

PC Audio Input

1 (Sharing with AV In)

RGB In (D-sub 15pin) - PC

1 Rear

LAN Port

1 Rear

RJ45(RJP interface)

1 Rear

TV link Configuration (phone jack type)

1 Rear

PTC Service Only (3.5 mm jack)

1 Rear

MPI Jack (RJ-12)

1 Rear

INTERFACE (Side)

HDMI In

2 Side

USB (2.0)

1 Side

BROADCASTING SYSTEM

Analog

Yes (NTSC)

Digital

Yes (ATSC /QAM/VSB)

REMOTE JACK PANEL COMPATIBILITY (RJP)

G-Link, teleadapt

CABINET

VESA™ Standard Mount Interface

400mm x 400mm

Color

Metallic Titan

Weight

67.2 Ibs

Carton

60.9” x 37.2” x 7.6”

Without Stand

57.6” x 38.5” x 2.3”

Weight (Without Stand)

64.0 Ibs

Weight (Carton)

80.5 Ibs

Bezel Width (L/R/U/B) on (mm)

12.0mm/12.0mm/ 17.5mm

Bezel Width (L/R/U/B) off (mm)

9.5mm/9.5mm/ 15.0mm

With Stand

57.6” x 35.4” x 12.4”

Swivel

Yes (± 20°) with Lock Down plate (± 20°/45°/90°) (29”/65” Non-swivel)

PANEL

Frame Rate

120Hz

Panel Technology

Direct LED

Native Resolution

1920 x 1080 (FHD)

Response Time

9ms

Viewing Angle(HxV)

178° x 178°

Panel Size

65” Class (64.53”)

Brightness

280 cd/m2

Contrast Ratio Static (Typ)

1,400:1

Dynamic Contrast Ratio (Typ)

2,000,000:1

POWER

Power Source

110 ~ 240V, 50/60Hz

Stand-by

under 0.5W

Watts (Typical)

54W

SPECIAL FEATURES

USB Cloning

Yes

HDMI-CEC

Yes

HTNG-CEC

Yes

Lock Mode

Yes

RF(1/2Tuner)

Yes (1 Tuner)

MHL

Yes

Pro:Centric

Yes (V)

Multi IR Code

Yes

IR Out

Yes (MPI Jack)

Kensington Lock

Yes

External Speaker Out

Yes (Variable/Fixed/Line Out, 3.5mm, Stereo, Single ended Type(GRD,L+,R+), 1W with 8Ω)

Applications (Pro:Centric Smart)

Yes (PCA3.0)

Auto Configuration

Yes (EzManager)

b-Lan

Yes

Remote Diagnosis

Yes (Self Diagnosis)

Commercial Grade Stand

Welcome Screen (Splash Image)

Yes

HCAP (GEM/Flash)

Yes

Audio Codec

AC3(Dolby Digital), EAC3, AAC, Mpeg, MP3, PCM

Multicast/Unicast ready

Yes (Pro:Centric Server)

Smart Energy Saving (Auto Power Off)

Yes

Pro:Idiom

Yes

SI Compatible (TVLink Protocol)

Yes (MPI protocol)

Hotel Mode/ PDM /Installer Menu

Yes (Installer Menu)

Auto Off / Auto Sleep

Yes

RJP Compatibility

LG,Teleadapt (RJ45, HDMI CEC), G-Link(HDMI-CEC)

RJP Interface

Yes (RJ45, HDMI)

Moving Picture Playback (SD/HD/Plus HD)

Divx HD

Video Mute

Yes

Credenza/Security Screw Hole

One Channel Map/Logical Channel Map

Yes (LCM)

Lock Down Plate

Motion eye care (intelligent sensor)

Yes

USB

Yes (USB 2.0)


JPEG

REQUIRED LISTINGS

Safety

cUL, UL, FCC, NOM

RoHS

Yes

Energy Star 6.1

Yes

VIDEO

Aspect Ratio

Yes, 5 Modes (16:9, Just Scan, Set By Program, 4:3, Zoom)

Triple XD Engine

Yes

Dynamic Color Enhancer

Yes

Real Cinema 24p (3:3 pull down)

Yes

UPC

65LY570H

7 19192 91766 8
