Edge-lit Smart IPTV with Ultra HD and Integrated b-LAN™

Name: Edge-lit Smart IPTV with Ultra HD and Integrated b-LAN™
Brand: LG Electronics
SKU: 43UV770H
Availability: Discontinued

DISCONTINUED

43UV770H

Edge-lit Smart IPTV with Ultra HD and Integrated b-LAN™

Key Features

All Specs

Pro:Centric® SMART
Integrated Pro:Idiom® DRM Technology
Ultra HD
webOS & Media Share Features
Commercial Grade Stand (Except 65UV770H)
NEW Dolby Vision™ High Dynamic Range (HDR) with HDR10 Compatibility

Compare

Specs & Resources

Collapse All

HOSPITALITY FEATURES

Yes

PDM (Installer menu), Welcome Screen (Splash Image), Insert Image (webOS default), Logical Channel Map, External Speaker Out, Instant ON, RJP Compatibility, b-LANTM embedded

DISPLAY

Frame Rate

T120

Resolution

3,840 x 2,160 (4K UHD)

Viewing Angle Degree

178°/178°

Type

Edge LED

Response Time (G to G)

8m/s

Diagonal Size

42.8"

Dynamic Contrast Ratio

1,000,000:1

Static Contrast Ratio

1,200:1

GENERAL FEATURES

Anti-theft System

Kensington Lock, Credenza/Security Screw Hole, Lock Down Plate

Management

Wake on RF, WOL (Wake on LAN) SNMP, Remote Diagnostics, MPI Protocol, IR Out, Multi IR Code, HTNG/HDMI-CEC

Installation

EZ-Manager, USB Cloning

USB

Moving Picture Playback (.asf, .wmv, .avi, .mp4, .m4v, .mov, .3gp, .3g2, .mkv, .mpg, .mpeg, .dat, .etc), Picture (jpeg, jpg, jpe, BMP, PNG), Audio Codec (.mp3, .wav, .OGG, .WMA, .flac)

Setting Option

Auto Off/Sleep Timer, Smart Energy Saving, Motion Eye care

AUDIO

Optical Sound Sync

Yes

Sound Mode

6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game)

Wireless Sound Sync

Yes

Audio Output / Speaker System

10W + 10W / 2.0 ch

DIMENSIONS

Vesa (mm)

200 x 200

W x H x D / Weight (w/o stand)

38.1" x 22.3" x 1.6" / 22.5lb

Bezel Width (L/R, U, B) : off bezel based

5.9, 5.9,14.7 (mm)

Stand

(±20/45/90°) Swivel

W x H x D / Weight (Carton)

46.5" x 26.0" x 7.5" / 34.0lb

W x H x D / Weight (with stand)

38.1" x 24.3" x 11.9" / 29.5lb

Bezel Width On (L/R, U, B)

8.9, 8.9,17.2 (mm)

WARRANTY/UPC

UPC

719192611573

SOLUTION

IP Return Path

Yes

Solution Type

Pro:Centric® SMART / Pro:Centric® Direct

Data Streaming (IP & RF)

Yes

Server

PCS400R, PCS200S

2 Tuner

Digital Rights Management

Pro:Idiom

HCAP (SDK)

GEM / Flash / HTML

BROADCASTING SYSTEM

MPEG-2 / MPEG-4 H.264 DECODING

Yes

Digital

ATSC / VSB / Clear QAM

Analog

NTSC

INTERFACE

Rear

RF In (b-LAN), AV In, Digital Optical Audio Out, HDMI Input, USB, RS-232C, RJ45(2), External Speaker Out, TV Link Confi guration (b-LAN Service), MPI Port, Debug

Side

HDMI In (2), USB 2.0

ACCESSORIES

Yes

Power Cable (5.9 ft.), Owner’s Manual / Easy Setup Guide

POWER

Voltage, Hz

100~240V, 50/60Hz

Watts (Typical)

51.4

Stand-by

< 0.5

SMART FEATURES

Connectivity

SoftAP, WiFi (802.11a/b/g/n/ac), ScreenShare (Miracast), SmartShare, DIAL, Bluetooth Sound Sync, LG Sound Sync

Smart UX

webOS 3.5, Commercial Smart Home, Web Browser, Pre-loaded Apps, SDP (Software Defined Perimeter), Magic Remote (Optional)

VIDEO

Aspect Ratio

6 modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom, Just Scan)

Triple XD Engine

Yes

Real Cinema 24p (3:3 pull down)

Yes

Picture Mode

9 modes (Vivid, Standard, APS (Eco), Cinema, Sports, Game, HDR Effect, Expert (Bright Room), Expert (Dark Room))

HDR

Dolby VisionTM HDR, HDR10

STANDARD CERTIFICATIONS

Etc.

RoHS, UL, ENERGY STAR® Qualifi ed, Dolby VisionTM

Environment

FCC

Safety

HOSPITALITY FEATURES

Yes

PDM (Installer menu), Welcome Screen (Splash Image), Insert Image (webOS default), Logical Channel Map, External Speaker Out, Instant ON, RJP Compatibility, b-LANTM embedded

DISPLAY

Frame Rate

T120

Resolution

3,840 x 2,160 (4K UHD)

Viewing Angle Degree

178°/178°

Type

Edge LED

Response Time (G to G)

8m/s

Diagonal Size

42.8"

Dynamic Contrast Ratio

1,000,000:1

Static Contrast Ratio

1,200:1

GENERAL FEATURES

Anti-theft System

Kensington Lock, Credenza/Security Screw Hole, Lock Down Plate

Management

Wake on RF, WOL (Wake on LAN) SNMP, Remote Diagnostics, MPI Protocol, IR Out, Multi IR Code, HTNG/HDMI-CEC

Installation

EZ-Manager, USB Cloning

USB

Moving Picture Playback (.asf, .wmv, .avi, .mp4, .m4v, .mov, .3gp, .3g2, .mkv, .mpg, .mpeg, .dat, .etc), Picture (jpeg, jpg, jpe, BMP, PNG), Audio Codec (.mp3, .wav, .OGG, .WMA, .flac)

Setting Option

Auto Off/Sleep Timer, Smart Energy Saving, Motion Eye care

AUDIO

Optical Sound Sync

Yes

Sound Mode

6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game)

Wireless Sound Sync

Yes

Audio Output / Speaker System

10W + 10W / 2.0 ch

DIMENSIONS

Vesa (mm)

200 x 200

W x H x D / Weight (w/o stand)

38.1" x 22.3" x 1.6" / 22.5lb

Bezel Width (L/R, U, B) : off bezel based

5.9, 5.9,14.7 (mm)

Stand

(±20/45/90°) Swivel

W x H x D / Weight (Carton)

46.5" x 26.0" x 7.5" / 34.0lb

W x H x D / Weight (with stand)

38.1" x 24.3" x 11.9" / 29.5lb

Bezel Width On (L/R, U, B)

8.9, 8.9,17.2 (mm)

WARRANTY/UPC

UPC

719192611573

SOLUTION

IP Return Path

Yes

Solution Type

Pro:Centric® SMART / Pro:Centric® Direct

Data Streaming (IP & RF)

Yes

Server

PCS400R, PCS200S

2 Tuner

Digital Rights Management

Pro:Idiom

HCAP (SDK)

GEM / Flash / HTML

BROADCASTING SYSTEM

MPEG-2 / MPEG-4 H.264 DECODING

Yes

Digital

ATSC / VSB / Clear QAM

Analog

NTSC

INTERFACE

Rear

RF In (b-LAN), AV In, Digital Optical Audio Out, HDMI Input, USB, RS-232C, RJ45(2), External Speaker Out, TV Link Confi guration (b-LAN Service), MPI Port, Debug

Side

HDMI In (2), USB 2.0

ACCESSORIES

Yes

Power Cable (5.9 ft.), Owner’s Manual / Easy Setup Guide

POWER

Voltage, Hz

100~240V, 50/60Hz

Watts (Typical)

51.4

Stand-by

< 0.5

SMART FEATURES

Connectivity

SoftAP, WiFi (802.11a/b/g/n/ac), ScreenShare (Miracast), SmartShare, DIAL, Bluetooth Sound Sync, LG Sound Sync

Smart UX

webOS 3.5, Commercial Smart Home, Web Browser, Pre-loaded Apps, SDP (Software Defined Perimeter), Magic Remote (Optional)

VIDEO

Aspect Ratio

6 modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom, Just Scan)

Triple XD Engine

Yes

Real Cinema 24p (3:3 pull down)

Yes

Picture Mode

9 modes (Vivid, Standard, APS (Eco), Cinema, Sports, Game, HDR Effect, Expert (Bright Room), Expert (Dark Room))

HDR

Dolby VisionTM HDR, HDR10

STANDARD CERTIFICATIONS

Etc.

RoHS, UL, ENERGY STAR® Qualifi ed, Dolby VisionTM

Environment

FCC

Safety
