43" class (42.8" diagonal) Smart Slim Direct LED IPTV with Pro:Idiom and Embedded b-LAN™

Name: 43" class (42.8" diagonal) Smart Slim Direct LED IPTV with Pro:Idiom and Embedded b-LAN™
Brand: LG Electronics
SKU: 43LX770H
Availability: Discontinued

DISCONTINUED

43LX770H

43" class (42.8" diagonal) Smart Slim Direct LED IPTV with Pro:Idiom and Embedded b-LAN™

Key Features

All Specs

Pro: Centric Smart SDK
Enhanced Customer Experience
Easy Content Creation & Management
Intuitive Experience

Compare

Specs & Resources

Collapse All

OTHER

UPC

7 19192 91790 3

Warranty

2-Year Limited Warranty Parts/Labor/Backlight/Extended warranty options are also available

AUDIO

Clear Voice

Yes

Sound Mode

6 Modes (Standard, News, Music, Cinema, Sport, Game)

Speaker System

2.0 ch

Audio Output

10W + 10W

Optical Sound Sync

Yes

Sound Optimizer

3 modes (Off, Wall-Mount Type, Stand Type)

Smart Sound Mode

Yes

apt-X codec

Yes

Wireless Sound Sync

Ready

Sound Expansion

Yes

DIMENSIONS

VESA®

200mm x 200mm

Bezel Width On (L/R, U, B)

14.9mm, 12.5mm, 17.6mm

Bezel Width Off (L/R, U, B)

12.6mm, 10.2mm, 15.3mm

Swivel Angle

±20° (±45° / 90° with option)

WxHxD (with Stand)

38.3"x24.6"x12.8"

Weight with stand

30.0lbs

WxHxD (w/o stand)

38.3"x22.3"x2.2"

Weight w/o stand

22.5lbs

WxHxD Packing

41.3"x25.8"x5.6"

Weight Packing

35.1lbs

FEATURES

Installer Menu

Yes

HDMI-CEC

Yes

HTNG-CEC

Yes

RJP Interface

RJ-45,HDMI

RJP Compatibility

Teleadapt (RJ-45, HDMI CEC), G-Link (HDMI-CEC)

USB

USB 2.0


JPEG

Audio Codec

AC3 (Dolby Digital), E-AC-3, AAC, MP3, PCM

Motion Eye Care

Yes

USB Cloning

Yes

Commercial Grade Stand

Yes (Except 65”)

Lock Down Plate

Yes

Bluetooth Sound Sync

Yes

Logical Channel Map

Yes

IR Pass Through

Yes (MPI Port)

Soft AP

Yes

Wi-Fi

Built-in

b-LAN

Yes

Pro:Idiom

Yes

DIAL

Yes

Wi-Fi Direct

Yes

Miracast

Yes

DLNA

Yes

Smart Share

Yes (RTSP, HLS, USB Video Streaming)

Remote App Compatibility

Yes

Magic Motion Remote

Yes

Web Browser

Yes

Comm Smart UX

Yes (Smart Home / Input)

SNMP

Yes

IP Streaming

UDP/Multicast, Smart Share (IGMPv3 SSM Support)

Auto Config SP

Ez-Manager

HCAP

GEM / Flash / HTML

1 Tuner

Hybrid Streaming

Yes (IP & RF) HTTP Data Carousel

Pro:Centric Smart

Yes

Remote Diagnosis

Yes

External Speaker Out

Variable/Fixed/Line Out, 3.5mm, Stereo, Single ended Type (GND) 1W with 8Ω

Moving Picture Playback (SD/HD/Plus HD)

Divx HD

Auto Off / Auto Sleep

Yes

Kensington Lock

Stand

Smart Energy Saving

Yes

Credenza/Security Screw Hole

Yes

Multicast/Unicast Ready

Yes

Pro:centric

Commercial CP/Apps

BROADCASTING SYSTEM

Analog

NTSC

Digital

ATSC/VSB/Clear QAM

SIDE

HDMI In

USB

1(2.0)

REAR

RF In

Digital Audio Out

1 (Optical)

LAN Port

AV In

1 Composite (Sharing with Component In) + Audio (L/R)

PC Audio Input

1 (Sharing with Component Audio in)

PTC Service

1 (3.5mm Jack)

HDMI

Component In

1 Y,Pb,Pr + Audio (L/R)

USB

1 (2.0)

Speaker Out/ Line Out

1 (3.5mm RJ-45 jack)

Service

1 (3.5mm Jack) Service Only

Game Control / MPI Port

1 (RJ-12)

TV-Link CFG

1 (3.5mm Jack)

PANEL

Viewing Angle Degree

178°/178°

Resolution

1920x1080 (FHD)

Frame Rate

60Hz

Response Time

8ms (G to G)

Dynamic Contrast Ratio (Typ)

1,000,000:1

Static (Panel) Contrast Ratio

1,200:1

Screen Size

43" class (42.8" diagonal)

ACCESSORIES

Manual/ESG

Simple book

Power Cord

Power cord (5.8’)

Remote Type

S-Con / Magic Motion RCU (sold separately)

POWER

Voltage, Hz

35.8W

Stand-by

<0.5W

REMOTE JACK PACK COMPATIBILITY (RJP)

G-Link

Yes

teleadapt

Yes

VIDEO

Aspect Ratio

5 modes (16:9, Just Scan, Set By Program, 4:3, Zoom)

Triple XD Engine

Yes

Dynamic Color Enhancer

Yes

Real Cinema 24p

Yes (3:3 pull down)

COMPATIBLE INTERACTIVE SYSTEMS (SEPARATE SET-TOP BOX MAY BE REQUIRED)

COMPATIBLE INTERACTIVE SYSTEMS

SQNIFI, BULK TV, acentric, GuestTek, Hoist Locatel, m-com, at-nisions, NEVOTEK, WOrld Cinema, Indepen, acutek solutions, inforvalue, Allin, tangerine, directstreams, exceptional innovation, quadriga smart tvda

OTHER

UPC

7 19192 91790 3

Warranty

2-Year Limited Warranty Parts/Labor/Backlight/Extended warranty options are also available

AUDIO

Clear Voice

Yes

Sound Mode

6 Modes (Standard, News, Music, Cinema, Sport, Game)

Speaker System

2.0 ch

Audio Output

10W + 10W

Optical Sound Sync

Yes

Sound Optimizer

3 modes (Off, Wall-Mount Type, Stand Type)

Smart Sound Mode

Yes

apt-X codec

Yes

Wireless Sound Sync

Ready

Sound Expansion

Yes

DIMENSIONS

VESA®

200mm x 200mm

Bezel Width On (L/R, U, B)

14.9mm, 12.5mm, 17.6mm

Bezel Width Off (L/R, U, B)

12.6mm, 10.2mm, 15.3mm

Swivel Angle

±20° (±45° / 90° with option)

WxHxD (with Stand)

38.3"x24.6"x12.8"

Weight with stand

30.0lbs

WxHxD (w/o stand)

38.3"x22.3"x2.2"

Weight w/o stand

22.5lbs

WxHxD Packing

41.3"x25.8"x5.6"

Weight Packing

35.1lbs

FEATURES

Installer Menu

Yes

HDMI-CEC

Yes

HTNG-CEC

Yes

RJP Interface

RJ-45,HDMI

RJP Compatibility

Teleadapt (RJ-45, HDMI CEC), G-Link (HDMI-CEC)

USB

USB 2.0


JPEG

Audio Codec

AC3 (Dolby Digital), E-AC-3, AAC, MP3, PCM

Motion Eye Care

Yes

USB Cloning

Yes

Commercial Grade Stand

Yes (Except 65”)

Lock Down Plate

Yes

Bluetooth Sound Sync

Yes

Logical Channel Map

Yes

IR Pass Through

Yes (MPI Port)

Soft AP

Yes

Wi-Fi

Built-in

b-LAN

Yes

Pro:Idiom

Yes

DIAL

Yes

Wi-Fi Direct

Yes

Miracast

Yes

DLNA

Yes

Smart Share

Yes (RTSP, HLS, USB Video Streaming)

Remote App Compatibility

Yes

Magic Motion Remote

Yes

Web Browser

Yes

Comm Smart UX

Yes (Smart Home / Input)

SNMP

Yes

IP Streaming

UDP/Multicast, Smart Share (IGMPv3 SSM Support)

Auto Config SP

Ez-Manager

HCAP

GEM / Flash / HTML

1 Tuner

Hybrid Streaming

Yes (IP & RF) HTTP Data Carousel

Pro:Centric Smart

Yes

Remote Diagnosis

Yes

External Speaker Out

Variable/Fixed/Line Out, 3.5mm, Stereo, Single ended Type (GND) 1W with 8Ω

Moving Picture Playback (SD/HD/Plus HD)

Divx HD

Auto Off / Auto Sleep

Yes

Kensington Lock

Stand

Smart Energy Saving

Yes

Credenza/Security Screw Hole

Yes

Multicast/Unicast Ready

Yes

Pro:centric

Commercial CP/Apps

BROADCASTING SYSTEM

Analog

NTSC

Digital

ATSC/VSB/Clear QAM

SIDE

HDMI In

USB

1(2.0)

REAR

RF In

Digital Audio Out

1 (Optical)

LAN Port

AV In

1 Composite (Sharing with Component In) + Audio (L/R)

PC Audio Input

1 (Sharing with Component Audio in)

PTC Service

1 (3.5mm Jack)

HDMI

Component In

1 Y,Pb,Pr + Audio (L/R)

USB

1 (2.0)

Speaker Out/ Line Out

1 (3.5mm RJ-45 jack)

Service

1 (3.5mm Jack) Service Only

Game Control / MPI Port

1 (RJ-12)

TV-Link CFG

1 (3.5mm Jack)

PANEL

Viewing Angle Degree

178°/178°

Resolution

1920x1080 (FHD)

Frame Rate

60Hz

Response Time

8ms (G to G)

Dynamic Contrast Ratio (Typ)

1,000,000:1

Static (Panel) Contrast Ratio

1,200:1

Screen Size

43" class (42.8" diagonal)

ACCESSORIES

Manual/ESG

Simple book

Power Cord

Power cord (5.8’)

Remote Type

S-Con / Magic Motion RCU (sold separately)

POWER

Voltage, Hz

35.8W

Stand-by

<0.5W

REMOTE JACK PACK COMPATIBILITY (RJP)

G-Link

Yes

teleadapt

Yes

VIDEO

Aspect Ratio

5 modes (16:9, Just Scan, Set By Program, 4:3, Zoom)

Triple XD Engine

Yes

Dynamic Color Enhancer

Yes

Real Cinema 24p

Yes (3:3 pull down)

COMPATIBLE INTERACTIVE SYSTEMS (SEPARATE SET-TOP BOX MAY BE REQUIRED)

COMPATIBLE INTERACTIVE SYSTEMS
