42" class (41.92" diagonal) with Integrated Pro:Idiom® and b-LA

Name: 42" class (41.92" diagonal) with Integrated Pro:Idiom® and b-LA
Brand: LG Electronics
SKU: 42LY570H
Availability: Discontinued

DISCONTINUED

42LY570H

42" class (41.92" diagonal) with Integrated Pro:Idiom® and b-LA

Key Features

All Specs

No need for printed materials for the guests
Reduced waste, save cost and time

Compare

Specs & Resources

Collapse All

WARRANTY

2-Year Limited Warranty (Parts/Labor)

AUDIO

Clear Voice II

Yes

Sound Mode

Yes, 6 Modes (Standard, News, Music, Cinema, Sport, Game)

Speaker System

2.0 ch

Audio Output

10W + 10W

Optical Sound Sync

Yes

Sound Optimizer

Yes (3 Modes: Normal, Wall-Mount Type, Stand Type)

INTERFACE (Rear)

RF In

1 Rear

AV In

1 Rear

Digital Audio Out

1 Rear (Optical)

HDMI/HDCP Input

1 Rear

External Speaker Out

1 Rear (3.5mm phone jack)

PC Audio Input

1 (Sharing with AV In)

RGB In (D-sub 15pin) - PC

1 Rear

LAN Port

1 Rear

RJ45(RJP interface)

1 Rear

TV link Configuration (phone jack type)

1 Rear

PTC Service Only (3.5 mm jack)

1 Rear

MPI Jack (RJ-12)

1 Rear

INTERFACE (Side)

HDMI In

2 Side

USB (2.0)

1 Side

BROADCASTING SYSTEM

Analog

Yes (NTSC)

Digital

Yes (ATSC /QAM/VSB)

REMOTE JACK PANEL COMPATIBILITY (RJP)

G-Link, teleadapt, LG

CABINET

VESA™ Standard Mount Interface

400mm x 400mm

Color

Metallic Titan

Weight

27.8 lbs

Carton

41.7” x 28.7” x 6.4”

Without Stand

37.8” x 22.3” x 2.2”

Weight (Without Stand)

20.3 lbs

Weight (Carton)

30.4 lbs

Bezel Width (L/R/U/B) on (mm)

11.0mm/11.0mm/16.5mm

Bezel Width (L/R/U/B) off (mm)

8.5mm/8.5mm/14mm

Bezel Depth (mm)

55.5mm

With Stand

37.8” x 24.3” x 12.8”

Swivel

Yes (± 20), with Lock Down plate (±20/45/90°)

PANEL

Frame Rate

60Hz

Panel Technology

Direct LED

Native Resolution

1920 x 1080 (FHD)

Response Time

8ms

Viewing Angle(HxV)

178° x 178°

Panel Size

42”Class(41.92")

Brightness

240 cd/m2

Contrast Ratio Static (Typ)

1,200:1

Dynamic Contrast Ratio (Typ)

2,000,000:1

POWER

Power Source

110 ~ 240V, 50/60Hz

Stand-by

under 0.5W

Power Cord Length

5.9’

Watts (Typical)

35W

SPECIAL FEATURES

USB Cloning

Yes

HDMI-CEC

Yes

HTNG-CEC

Yes

Lock Mode

Yes

RF(1/2Tuner)

Yes (1 Tuner)

MHL

Yes

Pro:Centric

Yes (V)

Multi IR Code

Yes

IR Out

Yes (MPI Jack)

Kensington Lock

Yes (Stand)

External Speaker Out

Yes (Variable/Fixed/Line Out, 3.5mm, Stereo, Single ended Type(GRD,L+,R+), 1W with 8Ω)

Applications (Pro:Centric Smart)

Yes (PCA3.0)

Auto Configuration

Yes (EzManager)

b-Lan

Yes

Remote Diagnosis

Yes (Self Diagnosis)

Commercial Grade Stand

Yes

Welcome Screen (Splash Image)

Yes

HCAP (GEM/Flash)

Yes

Audio Codec

AC3(Dolby Digital), EAC3, AAC, Mpeg, MP3, PCM

Multicast/Unicast ready

Yes (Pro:Centric Server)

Smart Energy Saving (Auto Power Off)

Yes

Pro:Idiom

Yes

SI Compatible (TVLink Protocol)

Yes (MPI protocol)

Hotel Mode/ PDM /Installer Menu

Yes (Installer Menu)

Auto Off / Auto Sleep

Yes

RJP Compatibility

LG,Teleadapt (RJ45, HDMI CEC), G-Link(HDMI-CEC)

RJP Interface

Yes (RJ45, HDMI)

Moving Picture Playback (SD/HD/Plus HD)

Divx HD

Video Mute

Yes

Credenza/Security Screw Hole

Yes

One Channel Map/Logical Channel Map

Yes (LCM)

Lock Down Plate

Yes (for easy installing )

Motion eye care (intelligent sensor)

Yes

USB

Yes (USB 2.0)


JPEG

REQUIRED LISTINGS

Safety

cUL, UL, FCC, NOM

RoHS

Yes

Energy Star 6.1

Yes

VIDEO

Aspect Ratio

Yes, 5 Modes (16:9, Just Scan, Set By Program, 4:3, Zoom)

Triple XD Engine

Yes

Dynamic Color Enhancer

Yes

Real Cinema 24p (3:3 pull down)

Yes

UPC

42LY570H

7 19192 91596 1

WARRANTY

2-Year Limited Warranty (Parts/Labor)

AUDIO

Clear Voice II

Yes

Sound Mode

Yes, 6 Modes (Standard, News, Music, Cinema, Sport, Game)

Speaker System

2.0 ch

Audio Output

10W + 10W

Optical Sound Sync

Yes

Sound Optimizer

Yes (3 Modes: Normal, Wall-Mount Type, Stand Type)

INTERFACE (Rear)

RF In

1 Rear

AV In

1 Rear

Digital Audio Out

1 Rear (Optical)

HDMI/HDCP Input

1 Rear

External Speaker Out

1 Rear (3.5mm phone jack)

PC Audio Input

1 (Sharing with AV In)

RGB In (D-sub 15pin) - PC

1 Rear

LAN Port

1 Rear

RJ45(RJP interface)

1 Rear

TV link Configuration (phone jack type)

1 Rear

PTC Service Only (3.5 mm jack)

1 Rear

MPI Jack (RJ-12)

1 Rear

INTERFACE (Side)

HDMI In

2 Side

USB (2.0)

1 Side

BROADCASTING SYSTEM

Analog

Yes (NTSC)

Digital

Yes (ATSC /QAM/VSB)

REMOTE JACK PANEL COMPATIBILITY (RJP)

G-Link, teleadapt, LG

CABINET

VESA™ Standard Mount Interface

400mm x 400mm

Color

Metallic Titan

Weight

27.8 lbs

Carton

41.7” x 28.7” x 6.4”

Without Stand

37.8” x 22.3” x 2.2”

Weight (Without Stand)

20.3 lbs

Weight (Carton)

30.4 lbs

Bezel Width (L/R/U/B) on (mm)

11.0mm/11.0mm/16.5mm

Bezel Width (L/R/U/B) off (mm)

8.5mm/8.5mm/14mm

Bezel Depth (mm)

55.5mm

With Stand

37.8” x 24.3” x 12.8”

Swivel

Yes (± 20), with Lock Down plate (±20/45/90°)

PANEL

Frame Rate

60Hz

Panel Technology

Direct LED

Native Resolution

1920 x 1080 (FHD)

Response Time

8ms

Viewing Angle(HxV)

178° x 178°

Panel Size

42”Class(41.92")

Brightness

240 cd/m2

Contrast Ratio Static (Typ)

1,200:1

Dynamic Contrast Ratio (Typ)

2,000,000:1

POWER

Power Source

110 ~ 240V, 50/60Hz

Stand-by

under 0.5W

Power Cord Length

5.9’

Watts (Typical)

35W

SPECIAL FEATURES

USB Cloning

Yes

HDMI-CEC

Yes

HTNG-CEC

Yes

Lock Mode

Yes

RF(1/2Tuner)

Yes (1 Tuner)

MHL

Yes

Pro:Centric

Yes (V)

Multi IR Code

Yes

IR Out

Yes (MPI Jack)

Kensington Lock

Yes (Stand)

External Speaker Out

Yes (Variable/Fixed/Line Out, 3.5mm, Stereo, Single ended Type(GRD,L+,R+), 1W with 8Ω)

Applications (Pro:Centric Smart)

Yes (PCA3.0)

Auto Configuration

Yes (EzManager)

b-Lan

Yes

Remote Diagnosis

Yes (Self Diagnosis)

Commercial Grade Stand

Yes

Welcome Screen (Splash Image)

Yes

HCAP (GEM/Flash)

Yes

Audio Codec

AC3(Dolby Digital), EAC3, AAC, Mpeg, MP3, PCM

Multicast/Unicast ready

Yes (Pro:Centric Server)

Smart Energy Saving (Auto Power Off)

Yes

Pro:Idiom

Yes

SI Compatible (TVLink Protocol)

Yes (MPI protocol)

Hotel Mode/ PDM /Installer Menu

Yes (Installer Menu)

Auto Off / Auto Sleep

Yes

RJP Compatibility

LG,Teleadapt (RJ45, HDMI CEC), G-Link(HDMI-CEC)

RJP Interface

Yes (RJ45, HDMI)

Moving Picture Playback (SD/HD/Plus HD)

Divx HD

Video Mute

Yes

Credenza/Security Screw Hole

Yes

One Channel Map/Logical Channel Map

Yes (LCM)

Lock Down Plate

Yes (for easy installing )

Motion eye care (intelligent sensor)

Yes

USB

Yes (USB 2.0)


JPEG

REQUIRED LISTINGS

Safety

cUL, UL, FCC, NOM

RoHS

Yes

Energy Star 6.1

Yes

VIDEO

Aspect Ratio

Yes, 5 Modes (16:9, Just Scan, Set By Program, 4:3, Zoom)

Triple XD Engine

Yes

Dynamic Color Enhancer

Yes

Real Cinema 24p (3:3 pull down)

Yes

UPC

42LY570H

7 19192 91596 1
