CREATE a MyLG Business Account to see special pricing.

4K UHD Hospital Grade Pro:Centric®SMART with Integrated Pro:Idiom and b-LAN™

Name: 4K UHD Hospital Grade Pro:Centric®SMART with Integrated Pro:Idiom and b-LAN™
Brand: LG Electronics
SKU: 55UV770M
Availability: Discontinued

DISCONTINUED

55UV770M

4K UHD Hospital Grade Pro:Centric®SMART with Integrated Pro:Idiom and b-LAN™

Key Features

All Specs

4K ULTRA HD Resolution
Designed Specifically for the Healthcare Industry
UL Hospital Grade Listed
RoHS Compliant
California Energy Commission (CEC) Compliant

Compare

Specs & Resources

Collapse All

CERTIFICATIONS

EMC

FCC

Safety

ETC.

RoHS, UL, NOM, Energy Star 7.0

OTHER

Warranty

2 Year Limited Warranty (Parts and Labor)

UPC

7 19192 91999 0

AUDIO

Clear Voice

Yes

Optical Sound Sync

Yes

Speaker System

2.0 ch

Audio Output

10W + 10W

Sound Mode

Yes 6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game)

Wireless Sound Sync

Yes

INTERFACE(REAR)

RF In

MPI Port (RJ12)

MPI Port (RJ12 jack)

Pillow Speaker Interface (6pin)

Digital Audio Out

1 (Optical)

RS-232C(D-Sub 9pin)

1 (TV link MNT, Phone jack type)

HDMI/HDCP Input

1 (2.0)

RJ45 (Ethernet/SVC/RJP Interface)

1 (Ethernet/SVC/RJP Interface)

Debug (Phone Jack Type)

1 (CPU/PTC Debug)

TV link Configuration (Phone Jack Type)

1 (b_LAN Service)

INTERFACE(SIDE)

USB (2.0)

1(2.0)

HDMI In

2 (2.0)

FUNCTION

IR Out

Yes (MPI Jack/HDMI)

Insert Image (No signal)

Yes (webOS Default)

Smart Energy Saving

Yes

Installer Menu

Yes

Logical Channel Map

Yes

RJP Interface

Yes (HDMI)

Moving Picture Playback (SD/HD/Plus HD)

.asf, .wmv, .avi, .mp4, .m4v, .mov, .3gp, .3g2, .mkv, .mpg, .mpeg, .dat, etc.


jpeg, jpg, jpe, BMP, PNG

Audio Codec

.mp3, .wav, .OGG, .WMA, .flac

Wake on RF

Yes

WOL

Yes

EZ-Manager

Yes

RJP Compatibility

Yes - Teleadapt/Guestlink (HDMI CEC)

Auto Off / Sleep Timer

Yes/Yes

Instant On

Yes

Pillow Speaker

Yes

SI Compatible (TVLink Interactive)

Yes (MPI protocol)

b-LAN embedded

Yes

SNMP

Yes

HDMI-CEC

Yes

Multi IR Code

Yes

External Speaker Out

Yes (Variable/Fixed/Line Out, 3.5mm, Stereo, Single ended Type(GND,L+,R+), 1W with 8Ω)

USB Cloning

Yes

Welcome Screen (Splash Image)

Yes

Motion Eye Care

Yes

Diagnostics

Yes (Remote Diagnosis)

HTNG-CEC

Yes

BROADCASTING SYSTEM

Digital

Yes (ATSC)

Terrestrial

VSB

Analog

Yes (NTSC)

Cable

Clear QAM/VSB

CABINET

Weight (Carton)

35.3 lbs

Bezel Width (on/off) (mm)

6.8/6.8/11.3

Bezel Width (Left/Right, Upper, Bottom) : on bezel (mm)

8.8/8.8/13.8

Dimensions (w/o Stand) (W x H x D)

53.5"x3.3"x6.0"

VESA™ Standard Mount Interface

300mm x 300mm

PANEL

Backlight Type

Edge

Frame Rate

T120

Response Time (G to G)

8ms

Viewing Angle Degree

178x178

Resolution

3840 X 2160 (4K UHD)

Static (Panel) Contrast Ratio

1200:1

ACCESSORIES

Manual/ESG

Yes (Simple Manual)

Anti-theft Dongle Cover

Yes

RS-232C(D-Sub 9pin)

1 (TV link MNT, Phone jack type)

Power Cable

Yes (5.9ft, Angle Type)

POWER

Voltage, Hz

120V, 50/60HZ

Watts (typical)

60.3

Stand-by

<0.5W

HOSPITALITY SOLUTION

Pro:Centric Smart

Yes

Pro:Idiom Software

Yes

RF (1/2Tuner)

Yes (2 Tuner)

Pro:Centric Direct

Yes

PCS200S

Yes

IP Return path

Yes

Pro:Centric Application (version)

Yes (PCA3.7.5)

Data Streaming (IP & RF)

Yes

Multicast/Unicast ready

Yes

webRTC

Yes

PCS400R

Yes

HCAP (GEM/FLASH/HTML) Service Carousel (TLL/XML)

GEM / Flash / HTML5

SMART FEATURES

Soft AP

Yes

WiFi (bandwidth)

Yes (802.11a/b/g/n/ac)

Bluetooth Sound Sync

Yes

Web Browser

Yes

LG Sound Sync/bluetooth

Yes

webOS version

webOS 3.5

Commercial Smart Home

Yes

Pre-loaded App

Yes

Magic Remote Compatibility

Yes (Optional)

DIAL

Yes

Smart Share (DLNA)

Yes

SDP Server compatibility

Yes

Screen Share (Miracast, WiDi)

Yes

VIDEO

XD Engine

Yes

Aspect Ratio

Yes 6 modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom, Just Scan)

HDR 10

Yes

Real Cinema 24p (3:3 pull down)

Yes

Picture Mode

Yes 9 modes (Vivid, Standard, APS(Eco), Cinema, Sports, Game, HDR Effect, Expert(Bright Room), Expert (Dark Room))

DESIGN

VESA Compatible

300mm x 300mm

Front Color

Shine Titan

CERTIFICATIONS

EMC

FCC

Safety

ETC.

RoHS, UL, NOM, Energy Star 7.0

OTHER

Warranty

2 Year Limited Warranty (Parts and Labor)

UPC

7 19192 91999 0

AUDIO

Clear Voice

Yes

Optical Sound Sync

Yes

Speaker System

2.0 ch

Audio Output

10W + 10W

Sound Mode

Yes 6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game)

Wireless Sound Sync

Yes

INTERFACE(REAR)

RF In

MPI Port (RJ12)

MPI Port (RJ12 jack)

Pillow Speaker Interface (6pin)

Digital Audio Out

1 (Optical)

RS-232C(D-Sub 9pin)

1 (TV link MNT, Phone jack type)

HDMI/HDCP Input

1 (2.0)

RJ45 (Ethernet/SVC/RJP Interface)

1 (Ethernet/SVC/RJP Interface)

Debug (Phone Jack Type)

1 (CPU/PTC Debug)

TV link Configuration (Phone Jack Type)

1 (b_LAN Service)

INTERFACE(SIDE)

USB (2.0)

1(2.0)

HDMI In

2 (2.0)

FUNCTION

IR Out

Yes (MPI Jack/HDMI)

Insert Image (No signal)

Yes (webOS Default)

Smart Energy Saving

Yes

Installer Menu

Yes

Logical Channel Map

Yes

RJP Interface

Yes (HDMI)

Moving Picture Playback (SD/HD/Plus HD)

.asf, .wmv, .avi, .mp4, .m4v, .mov, .3gp, .3g2, .mkv, .mpg, .mpeg, .dat, etc.


jpeg, jpg, jpe, BMP, PNG

Audio Codec

.mp3, .wav, .OGG, .WMA, .flac

Wake on RF

Yes

WOL

Yes

EZ-Manager

Yes

RJP Compatibility

Yes - Teleadapt/Guestlink (HDMI CEC)

Auto Off / Sleep Timer

Yes/Yes

Instant On

Yes

Pillow Speaker

Yes

SI Compatible (TVLink Interactive)

Yes (MPI protocol)

b-LAN embedded

Yes

SNMP

Yes

HDMI-CEC

Yes

Multi IR Code

Yes

External Speaker Out

Yes (Variable/Fixed/Line Out, 3.5mm, Stereo, Single ended Type(GND,L+,R+), 1W with 8Ω)

USB Cloning

Yes

Welcome Screen (Splash Image)

Yes

Motion Eye Care

Yes

Diagnostics

Yes (Remote Diagnosis)

HTNG-CEC

Yes

BROADCASTING SYSTEM

Digital

Yes (ATSC)

Terrestrial

VSB

Analog

Yes (NTSC)

Cable

Clear QAM/VSB

CABINET

Weight (Carton)

35.3 lbs

Bezel Width (on/off) (mm)

6.8/6.8/11.3

Bezel Width (Left/Right, Upper, Bottom) : on bezel (mm)

8.8/8.8/13.8

Dimensions (w/o Stand) (W x H x D)

53.5"x3.3"x6.0"

VESA™ Standard Mount Interface

300mm x 300mm

PANEL

Backlight Type

Edge

Frame Rate

T120

Response Time (G to G)

8ms

Viewing Angle Degree

178x178

Resolution

3840 X 2160 (4K UHD)

Static (Panel) Contrast Ratio

1200:1

ACCESSORIES

Manual/ESG

Yes (Simple Manual)

Anti-theft Dongle Cover

Yes

RS-232C(D-Sub 9pin)

1 (TV link MNT, Phone jack type)

Power Cable

Yes (5.9ft, Angle Type)

POWER

Voltage, Hz

120V, 50/60HZ

Watts (typical)

60.3

Stand-by

<0.5W

HOSPITALITY SOLUTION

Pro:Centric Smart

Yes

Pro:Idiom Software

Yes

RF (1/2Tuner)

Yes (2 Tuner)

Pro:Centric Direct

Yes

PCS200S

Yes

IP Return path

Yes

Pro:Centric Application (version)

Yes (PCA3.7.5)

Data Streaming (IP & RF)

Yes

Multicast/Unicast ready

Yes

webRTC

Yes

PCS400R

Yes

HCAP (GEM/FLASH/HTML) Service Carousel (TLL/XML)

GEM / Flash / HTML5

SMART FEATURES

Soft AP

Yes

WiFi (bandwidth)

Yes (802.11a/b/g/n/ac)

Bluetooth Sound Sync

Yes

Web Browser

Yes

LG Sound Sync/bluetooth

Yes

webOS version

webOS 3.5

Commercial Smart Home

Yes

Pre-loaded App

Yes

Magic Remote Compatibility

Yes (Optional)

DIAL

Yes

Smart Share (DLNA)

Yes

SDP Server compatibility

Yes

Screen Share (Miracast, WiDi)

Yes

VIDEO

XD Engine

Yes

Aspect Ratio

Yes 6 modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom, Just Scan)

HDR 10

Yes

Real Cinema 24p (3:3 pull down)

Yes

Picture Mode

Yes 9 modes (Vivid, Standard, APS(Eco), Cinema, Sports, Game, HDR Effect, Expert(Bright Room), Expert (Dark Room))

DESIGN

VESA Compatible

300mm x 300mm

Front Color

Shine Titan
