43” class (42.8" diagonal)
DISCONTINUED
43LX570M
43” class (42.8" diagonal)
Compare
Specs & Resources
GENERAL FEATURES
Pro:Centric Application
Yes
Moving Picture Playback (SD/HD/Plus HD)
Divx HD
Pro:Centric Remote Management
Yes
RF (1/2Tuner)
Yes (1 Tuner)
Auto Configuration
Yes (EZ-Manager)
Remote Diagnosis
Yes
Multicast/Unicast ready
Yes
HTNG-CEC 1.3
Yes
Pro:Idiom
Yes
SI Compatible
Yes (MPI protocol)
b-LAN
Yes
Installer Menu
Yes
IR Out
Yes (MPI port)
External Speaker Out
Yes (Variable/Fixed/Line Out, 3.5mm, Stereo, Single-ended Type [GND, L+, R+], 1W with 8Ω)
USB
Yes (USB 2.0)
JPEG
Audio Codec
AC3 (Dolby Digital), EAC3, AAC, Mpeg, MP3, PCM
USB Cloning
Yes
One Channel Map / FTG Channel Map
Yes
Multi IR Code
Yes
Welcome Screen
Yes
Auto Off / Auto Sleep
Yes
Video Mute
Yes
Smart Energy Saving
Yes (Auto Power Off)
Motion Eye Care
Yes
Kensington Lock
Yes
UL Hospital Safety Compliant
Yes
Pillow Speaker
Yes
OTHER
UPC
7 19192 91823 8
Audio
Sound Mode
Yes (6 Modes: Standard, News, Music, Cinema, Sport, Game)
Speaker System
2.0 ch
Optical Sound Sync
Yes
Sound Optimizer
Yes 2 modes (Normal, Wall-Mount Type)
Audio Output
43" : 10W + 10W
INTERFACE (REAR)
RF In
1
GAME CONTROL/MPI Port
1 (RJ-12)
TV Link Configuration
1 (3.5mm Jack)
PTC Configuration
1 (3.5mm jack)
Pillow Speaker Interface (6pin)
1 6pin
AV In
1
Digital Audio Out
1 (Optical)
HDMI/HDCP Input
1 (W/O MHL)
External Speaker Out
1 (3.5mm Jack)
INTERFACE (Side)
HDMI In
1
AV In
No
USB (2.0)
1
BROADCASTING SYSTEM
Analog
Yes (NTSC)
Digital
Yes
Terrestrial
ATSC
CABINET
WxHxD
38.3”x22.6”x2.2”
Weight
22.5 Ibs
Carton
41.3”x25.8”x5.6”
Carton Weight
26.9lbs
PANEL
Diagonal Class
43” class (42.8" diagonal)
Viewing Angle Degree
178/178
Static Contrast Ratio
1200:1
Backlight Type
Edge LED
Resolution
1920x1080 (FHD)
Frame Rate
60Hz
Dynamic Contrast Ratio
1,000,000:1
Response Time (G to G)
8ms
TOOL DESCRIPTION
Bezel Width (Left/Right, Upper, Bottom) OFF
12.6, 10.2, 15.3
Bezel Width (Left/Right, Upper, Bottom) ON
14.9, 12.5, 17.6
Flame Retardent
Yes
VESA Compatible
200mm x 200mm
ACCESSORIES
Power Cable
Hospital Power Cable
Owner's Manual / Easy Setup Guide
Yes
POWER
Typical (Watts) (Energy Star 7.0)
42W
Voltage
120V
Stand-by
<0.5W
Video
Aspect Ratio
Yes (5 Modes: 16:9, Just scan, Set by program, 4:3, Zoom)
Picture Mode
Yes (6 Modes: Vivid, Standard, Eco, Cinema, Sport, Game)
Triple XD Engine
Yes
CERTIFICATION
Safety / EMC / ETC.
UL / FCC / RoHS, cUL, NOM
All image simulations are for illustration purposes only.
