28” class (27.6” diagonal)
DISCONTINUED
28LX570M
28” class (27.6” diagonal)
Compare
Specs & Resources
INTERFACE (Side)
HDMI In
1
USB (2.0)
1
AV In
1 (Cable Included)
BROADCASTING SYSTEM
Analog
Yes (NTSC)
Digital
Yes
Terrestrial
ATSC
AUDIO
Audio Output
32" : 5W + 5W
Sound Mode
Yes (6 Modes: Standard, News, Music, Cinema, Sport, Game)
Optical Sound Sync
Yes
Sound Optimizer
Yes 2 modes (Normal, Wall-Mount Type)
Speaker System
2.0 ch
OTHER
UPC
7 19192 91785 9
VIDEO
Triple XD Engine
Yes
Aspect Ratio
Yes (5 Modes: 16:9, Just scan, Set by program, 4:3, Zoom)
Picture Mode
Yes (6 Modes: Vivid, Standard, Eco, Cinema, Sport, Game)
CERTIFICATION
Safety / EMC / ETC.
UL / FCC / RoHS, cUL, NOM, Energy Star 7.0
GENERAL FEATURES
Pro:Centric ® Application
PCA 3.5 or later
Moving Picture Playback (SD/HD/Plus HD)
Divx HD
Pro:Centric Remote Management
Yes
RF (1/2Tuner)
Yes (1 Tuner)
Auto Configuration
Yes (EZ-Manager)
Remote Diagnosis
Yes
Multicast/Unicast ready
Yes
HTNG-CEC 1.3
Yes
Pro:Idiom
Yes
SI Compatible
Yes (MPI protocol)
b-LAN
Yes
Installer Menu
Yes
IR Out
Yes (MPI port)
External Speaker Out
Yes (Variable/Fixed/Line Out, 3.5mm, Stereo, Single-ended Type [GND, L+, R+], 1W with 8Ω)
USB Media
Moving Picture Playback (DivX HD), Picture (JPEG), Audio Codec (AC3, EAC3, AAC, Mpeg, MP3, PCM)
JPEG
Audio Codec
AC3 (Dolby Digital), EAC3, AAC, Mpeg, MP3, PCM
USB Cloning
Yes
One Channel Map / FTG Channel Map
Yes
Multi IR Code
Yes
Welcome Screen
Yes
Auto Off / Auto Sleep
Yes
Video Mute
Yes
UL Hospital Safety Compliant
Yes
Smart Energy Saving
Yes (Auto Power Off)
Motion Eye Care
Yes
Kensington Lock
Yes
Pillow Speaker
Yes
CABINET
Carton Weight
13.0lbs
Weight
9.9lbs
Carton
28.5” x 18.5” x 6.0”
WxHxD
25.3” x 15.6” x 2.3”
WARRANTY
WARRANTY
2-Year Limited Warranty (Parts and Labor) | Extended Warranties Available
TOOL DESCRIPTION
Bezel Width (Left/Right, Upper, Bottom) OFF
14.3, 13.7, 22.5
Bezel Width (Left/Right, Upper, Bottom) ON
16, 15.4, 24.1
Flame Retardent
Yes
VESA Compatible
100mm x 100mm
POWER
Voltage
120V
Typical (Watts) (Energy Star 7.0)
26W
Stand-by (Watts)
<0.5W
PANEL
Backlight Type
Edge LED
Resolution
1366 x 768 (HD)
Frame Rate
60Hz
Dynamic Contrast Ratio
1,000,000:1
Response Time (G to G)
9ms
Inch
28” class (27.6" diagonal)
Viewing Angle Degree
178/178
Static Contrast Ratio
1000:1
ACCESSORIES
Power Cable
Hospital Power Cable
Owner's Manual / Easy Setup Guide
Yes
INTERFACE (Rear)
RF In
1
AV In
No
HDMI/HDCP Input
1 (W/O MHL)
External Speaker Out
1 (3.5mm Jack)
GAME CONTROL/MPI Port
1 (RJ-12)
TV Link Configuration
1 (3.5mm Jack)
PTC Configuration
1 (3.5mm jack)
Pillow Speaker Interface (6pin)
1 6pin
Digital Audio Out
1 (Optical)
All image simulations are for illustration purposes only.
