22” class (21.6" diagonal)
DISCONTINUED
22LX570M
22” class (21.6" diagonal)
Compare
Specs & Resources
GENERAL FEATURES
Pro:Centric Application
Yes
Moving Picture Playback (SD/HD/Plus HD)
Divx HD
Pro:Centric Remote Management
Yes
RF (1/2Tuner)
Yes (1 Tuner)
Auto Configuration
Yes (EZ-Manager)
Remote Diagnosis
Yes
Multicast/Unicast ready
Yes
HTNG-CEC 1.3
Yes
Pro:Idiom
Yes
SI Compatible
Yes (MPI protocol)
b-LAN
Yes
Installer Menu
Yes
IR Out
Yes (MPI port)
External Speaker Out
Yes (Variable/Fixed/Line Out, 3.5mm, Stereo, Single-ended Type [GND, L+, R+], 1W with 8Ω)
USB
Yes (USB 2.0)
JPEG
Audio Codec
AC3 (Dolby Digital), EAC3, AAC, Mpeg, MP3, PCM
USB Cloning
Yes
One Channel Map / FTG Channel Map
Yes
Multi IR Code
Yes
Welcome Screen
Yes
Auto Off / Auto Sleep
Yes
Video Mute
Yes
Smart Energy Saving
Yes (Auto Power Off)
Motion Eye Care
Yes
Kensington Lock
Yes
UL Hospital Safety Compliant
Yes
Pillow Speaker
Yes
OTHER
UPC
7 19192 91788 0
WARRANTY
WARRANTY
2-Year Limited Warranty (Parts and Labor) | Extended Warranties Available
AUDIO
Sound Mode
Yes (6 Modes: Standard, News, Music, Cinema, Sport, Game)
Speaker System
2.0 ch
Audio Output
32" : 5W + 5W
Optical Sound Sync
Yes
Sound Optimizer
Yes 2 modes (Normal, Wall-Mount Type)
INTERFACE (Rear)
RF In
1
GAME CONTROL/MPI Port
1 (RJ-12)
TV Link Configuration
1 (3.5mm Jack)
PTC Configuration
1 (3.5mm jack)
Pillow Speaker Interface (6pin)
1 6pin
AV In
1
Digital Audio Out
1 (Optical)
HDMI/HDCP Input
1 (W/O MHL)
External Speaker Out
1 (3.5mm Jack)
INTERFACE (Side)
HDMI In
1
AV In
No
USB (2.0)
1
BROADCASTING SYSTEM
Analog
Yes (NTSC)
Digital
Yes
Terrestrial
ATSC
CABINET
WxHxD
20.0” x 12.4” x 2.1”
Weight
6.4lbs
Carton
22.8” x 15.1” x 5.5”
Carton Weight
8.6lbs
PANEL
Viewing Angle Degree
178/178
Static Contrast Ratio
1000:1
Backlight Type
LED (Direct)
Resolution
1366 x 768 (HD)
Frame Rate
60Hz
Dynamic Contrast Ratio
1,000,000:1
Response Time (G to G)
9ms
Inch
21” class (21.6" diagonal)
TOOL DESCRIPTION
Bezel Width (Left/Right, Upper, Bottom) OFF
13, 14.6, 19.2
Bezel Width (Left/Right, Upper, Bottom) ON
14.7, 16.2, 20.8
Flame Retardent
Yes
VESA Compatible
75mm x 75mm
ACCESSORIES
Power Cable
Hospital Power Cable
Owner's Manual / Easy Setup Guide
Yes
POWER
Typical (Watts) (Energy Star 7.0)
20W
Voltage
120V
Stand-by
<0.5W
VIDEO
Aspect Ratio
Yes (5 Modes: 16:9, Just scan, Set by program, 4:3, Zoom)
Picture Mode
Yes (6 Modes: Vivid, Standard, Eco, Cinema, Sport, Game)
Triple XD Engine
Yes
CERTIFICATION
Safety / EMC / ETC.
UL / FCC / RoHS, cUL, NOM, Energy Star 7.0
All image simulations are for illustration purposes only.
