LBCK Ceiling Direct View LED for Virtual Production
LBCK039
LBCK Ceiling Direct View LED for Virtual Production
Key Features
All Specs
- Brompton LED Processor & Data Distribution
- Front or Rear Serviceability
- 5,000 nit Brightness
- Easy Installation and Maintenance
Compare
Specs & Resources
Physical Parameters
Pixel Pitch
3.91 mm
Module Resolution (W x H)
64 × 128
Module Dimensions (W x H)
9.84 x 19.68 in / 250 × 500 mm
Weight per Module
3.08 lbs / 1.40 kg
No. of Modules per Cabinet (W x H)
2 × 2
Cabinet Resolution (W x H)
128 × 256
Cabinet Dimensions (W x H x D)
19.68 x 39.37 x 2.60 in / 500 × 1,000 × 66.05 mm
Cabinet Surface Area
0.500 m²
Weight per Cabinet
12.5 kg
Weight per Unit Area
24.9 kg/m²
Physical Pixel Density
65,536 pixels/m²
Flatness of Cabinet
±0.3 mm
Cabinet Material
Die-Cast Magnesium
Service Access
Front or Rear (select one only)
90 Degree Corner Cut
No
Controller
Brompton SX40
Warranty & Other
Warranty
3 Year Limited
Environmental Conditions
Operating Humidity
10% to 99% RH
Operating Temperature
-22° to 45° F / -30° to 45° C
Regulatory & Certifications
ETL (Regulatory)
Yes
RoHS (Environmental)
Yes
FCC (Regulatory)
Yes
CE (Regulatory)
Yes
Electrical
Power Supply
100-240V
Refresh Rate
3,840 Hz
Frame Rate
50 / 60 Hz
Power Consumption per Cabinet (Avg.)
100 W
Power Consumption per Cabinet (Max.)
600 W
Heat Dissipation per Cabinet (Avg.)
341 BTU/h
Power Consumption per Unit Area (Max.)
1,024 W
Heat Dissipation per Cabinet (Max.)
1,024 BTU/h
Heat Dissipation per Unit Area (Max.)
2,047 BTU/h
Optical
Color Temperature
2,000-11,000K
Brightness Uniformity
97%
Color Uniformity
±0.003 Cx, Cy
Contrast Ratio
6,000:1
Processing Depth
14 bit (PQ, HLG)
Visual Viewing Angle (H x V)
160° x 155°
Lifetime (Half brightness)
Up to 100,000 hrs
All image simulations are for illustration purposes only.
