6.66mm GSCC Series Outdoor LED with Customizable Screen Ratio, 5,000nits Brightness, IP65 Rated, 90° Corner Options & Easy Assembly & Maintenance
DISCONTINUED
GSCC066-GN
6.66mm GSCC Series Outdoor LED with Customizable Screen Ratio, 5,000nits Brightness, IP65 Rated, 90° Corner Options & Easy Assembly & Maintenance
Key Features
All Specs
- Pixel Pitch: 6.66mm
- Brightness: 5,000nits
- Fast Assembly and Easy Maintenance
- IP65 Weatherproof Design
- 90º Corner Option Available
- Rental/Staging/Temporary deployments
Compare
Specs & Resources
PHYSICAL PARAMETERS
Pixel Configuration
3 in 1 SMD
No. of Modules per Unit Case (W x H)
2 x 3
Physical Pixel Density (pixels/m²)
2,091pixels/ft² | 22,500pixels/m²
Flatness of Unit Case (mm)
±0.5
Unit Case Material
Die-cast Aluminum
Service Access
Front or Rear (select one only)
Module Resolution (W x H)
48 x 36
Module Dimensions (W x H)
12.6 x 9.4 in/320 x 240 mm
Weight per Module
2.9 lbs/1.3kg
LED Package Manufacturer
Nationstar
Unit Case Dimensions (W x H x D)
25.2 x 28.3 x 4.4 in/640 x 720 x 112.9 mm
Unit Case Surface Area
4.96 ft²/0.461m²
Weight per Unit Case
37.5 lbs/17kg
Pixel Pitch
6.67mm
Weight per Square Meter
7.6 lb/ft²/36.9kg/m²
Unit Case Resolution (W x H, pixels)
96 x 108
CERTIFICATIONS
CE (Regulatory
Yes
ETL (Safety)
Yes
RoHS (Environmental)
Yes
FCC (Regulatory)
Yes
OPTICAL SPECIFICATIONS
Color Temperature
3,500 to 9,000 K
Visual Viewing Angle (Horizontal)
160°
Visual Viewing Angle (Vertical)
120°
Brightness Uniformity
97%
Color Uniformity
±0.003Cx,Cy
Contrast Ratio
5,000
Brightness
5,000nits
Processing Depth
14 bit
CONTROLLER
Controller
LCIN006
ELECTRICAL SPECIFICATIONS
Max Power Consumption per Unit
330W
Average Power Consumption per Unit
110W
Max Power Consumption per Unit Area
720W/m²
Max Power Consumption per Unit
1126 BTU
Average Power Consumption per Unit
375 BTU
Max Power Consumption per Unit Area
2,457 BTU/m²
Power Supply
100 to 240 Vac
Frame Rate
50/60 Hz
Refresh Rate
3840Hz
OPERATION SPECIFICATIONS
Operating Temperature
-4°F to 122°F/-20°C to +50°C
Operating Humidity
10-99% RH
IP Rating Front
IP65
IP Rating Rear
IP54
LED Lifetime (Half brightness)
100,000 hrs
All image simulations are for illustration purposes only.
