24mm Self-adhesive Transparent Color LED Film with Concave & Convex Curvature, webOS™ Smart Platform & Control Manager
DISCONTINUED
LAT240DT1
24mm Self-adhesive Transparent Color LED Film with Concave & Convex Curvature, webOS™ Smart Platform & Control Manager
Key Features
All Specs
- Pitch: 24mm
- LED Type: R,G,B 3in1 Color Package
- Transmittance: 73%
- Curvature(Convex and Concave): 1,100R
- Self-adhesive Film
Compare
Specs & Resources
1st Bezel Kit
Dimensions (W x H x D)
18.9" x 0.9" x 2.1" / 479.5 × 24 × 53 mm
Weight
1.0 lb / 0.45 kg
Common Bezel Kit
Dimensions (W x H x D)
18.9" x 0.9" x 1.1" / 479.5 × 24 × 28 mm
Weight
0.6 lbs / 0.26 kg
System Controller
Accessories
Power Cord, HDMI Cable, IR Sensor, 4P Phone-to-RS232C Gender
CMS S/W
Yes
Dimensions (W x H x D)
10.7" x 7.4" x 1.5" / 273 × 186.8 × 37 mm
Input
HDMI, DP, DVI-D, RS232C, RJ45 (w/o LED Indicator), IR Receiver (for Installation), USB 3.0
Light Sensor
O
Output
LVDS, DP, RS232C, RJ45 (w/o LED Indicator)
Power consumption
17 W
Source Selection
HDMI, DVI-D, DP
Temperature Sensor
O
TPC
Yes
Video
3,840 x 2,160 @30Hz
Weight (Head)
3.5 lbs / 1.6 kg
Power(Bezel Kit & LED Film)
Color
White
DC Output Cable
14AWG, 4.9' / 1.5m
Dimensions (W x H x D)
7.2" x 3.4" x 1.1" / 183 × 86 × 28 mm
Input
100~240V, 50~60Hz
Output
19.5V/10.8A (210W)
Weight
1.7 lbs / 0.769 kg
LED Film
Adhesion (After Installation)
50,000 Hrs
Brightness
>1,000 nits
Color Chromaticity
Cx: 0.28±0.03, Cy: 0.28±0.03
Color Processing
130/120/110 Level (R, G, B)
Colors
1,716,000 Colors
Contrast Ratio
≥ 100,000:1
Curved Installation
1,100R (Concave)
Daily Usage
24 Hrs / 7 Days
Dimensions (W x H x D)
26.3" x 18.9" x 0.8" / 668 x 480 x 2.0 mm (with Front & Back Protection Film)
Film Trimming
Yes (Parallel to the Bezel Side Only)
LED Type
R, G, B 3in1 Color Package (SMD1818)
Life Time (Brightness 50%)
50,000 Hrs
Luminance Uniformity
≥ 70%
Operating Temperature
32°F~ 113°F / 0°C ~ 45oC (Indoor Glass Installation Only)
Pitch
24 mm
Pixel Density [points/m2]
1,736
Power consumption
37 W (Transparent Panel and Bezel Kit, @ film 1ea), 150 W (Transparent Panel and Bezel Kit, @ film 2x2)
Resolution
28 x 20
Transmittance
73%
Viewing Angle (H x V)
120° x 120°
Weight
1.6 lbs / 0.73 kg
Unit Controller
Accessories
Power Cord, LVDS MCX Cable, ESG, Regulation Book
Dimensions (W x H x D)
10.7" x 7.4" x 1.5" / 273 × 186.8 × 37 mm
Interface
LVDS in with I2C, RJ45 x 4ea
Maximum Transmission Length
328.1' / 100m
Power consumption
20 W
Resolution
Up to FHD (4 Unit Controllers Needed for FHD)
Weight
3.3 lbs / 1.5 kg
All image simulations are for illustration purposes only.
