DISCONTINUED 171" LAED All-in-One Direct View LED Display with 21:9 Aspect Ratio, Embedded Controller, & Built-in Speakers
DISCONTINUED
LAED015
DISCONTINUED 171" LAED All-in-One Direct View LED Display with 21:9 Aspect Ratio, Embedded Controller, & Built-in Speakers
Key Features
All Specs
- This product has been DISCONTINUED. See all our current Direct View LED.
Compare
Specs & Resources
Physical Parameters
LED Type
Single SMD
Pixel Pitch
1.56 mm
Screen Size (Inches)
171"
Screen Resolution (W x H)
2,560 x 1,080 (21:9 WFHD)
Module Resolution (W x H)
160 x 180
Module Dimensions (W x H)
9.84 x 11.07 in / 250 x 281.25 mm
No. of Modules per Screen (W x H)
96 (16 x 6)
Screen Dimensions (W x H x D)
157.6 x 66.6 x 3.5 in / 4,003 x 1,692 x 70 mm
Screen Surface Area
72.68 ft² / 6.752 m²
Weight
366 lbs / 166 kg
Physical Pixel Density
409,600 pixels/m²
Flatness of Cabinet
±0.2 mm
Cabinet Material
Die-cast Aluminum
Service Access
Front
Electrical
Heat Dissipation (Max.)
7,165 BTU
Power Supply
100-240V
Heat Dissipation (Avg.)
2866 BTU
Power Consumption (Max.)
2100W
Power Supply
100-240V
Refresh Rate
2,880 Hz
Frame Rate
50 / 60 Hz
Power Consumption (Avg.)
840W
Power Consumption per Unit Area (Max.)
311 W/m²
Heat Dissipation per Unit Area (Max.)
1062 BTU/m²
Connectivity
HDMI In
Yes (x3)
IR In (3.5 mm)
Yes (x1)
DisplayPort In
Yes (x1)
RS-232C In (3.5 mm 4-pin)
Yes (x1)
RJ45 (LAN)
Yes (x1)
USB Type-A In
Yes (x1) USB 2.0
AC In
Not Available
Optical Digital Audio Out
Yes (x1)
Controller
Controller
Embedded
Optical
Max. Brightness (After Calibration)
Up to 500 nits
Color Temperature
3,200-9,300K
Viewing Angle (H x V)
160° x 160°
Brightness Uniformity
98%
Color Uniformity
±0.015 Cx, Cy
Contrast Ratio
3000:1
Processing Depth
16 bit (HDR10, HDR10 Pro)
Lifetime
up to 100,000 hrs (Half Brightness)
Audio/Sound
Built-in Speakers
Yes (x2) 9W
Features
Magic Remote Compatibility
Yes
Crestron Certified Compatibility
Yes
LG Software Compatible
ConnectedCare™
Yes
LG One:Quick Share
Yes
Regulatory & Certifications
ETL (Regulatory)
Yes
IP Rating (Rear)
IP20
IP Rating (Front)
IP30
CB
Yes
REACH (Environmental)
Yes
Safety 60950-1
No
CE (Regulatory)
Yes
RoHS (Environmental)
Yes
FCC (Regulatory)
Yes
BS476 Part7 (UK Fire Rating)
No
cTUVus
No
TAA Compliance
No
Warranty & Other
Warranty
3 Year Limited
Assembled In
China
Onscreen Display Languages
Not Available
Optional Accessories
Floor Stand
Basic Accessories (included)
Wall Mount
Environmental Conditions
Operation Humidity
10-80% RH
Operation Temperature
-4°F to 104°F / -20°C to 40°C
