UH5E Series
DISCONTINUED
98UH5E-B
UH5E Series
Key Features
All Specs
- Brightness(Typ.) : 500 cd/m²
- Bezel : 14.9 mm (Even, Off-Bezel)
- Depth : 57.9 mm (without Handle and Logo)
- Interface : HDMI(3)/DP/DVI-D/USB 2.0(2)/ RS232C/ RJ45/ Audio/ IR
Compare
Specs & Resources
PHYSICAL SPECIFICATIONS
Carton Dimensions (W x H x D)
92.2" x 54.6" x 15.8" / 2,342 x 1,386 x 402 mm
Handle
Yes
Monitor Dimension (W x H x D)
86..3" x 49.1" x 2.7" / 2,191.8 x 1,246.8 x 69.4 mm (without Handle)
Bezel Color
Black
Weight (Head)
194 lbs / 88 kg
Bezel Width
14.9mm (Even, Off-Bezel)
VESA TM Standard Mount Interface
800 x 400 mm
Packed Weight
271.2 lbs / 123 kg
OTHER
UPC
719192624597
CONNECTIVITY
Input
HDMI (3), DP, DVI-D, Audio, USB 2.0 (2)
Output
DP, Audio (Off/Fixed/Variable), External Speaker
External Control
RS232C In/out (4 Pin Phone-Jack), RJ45 (LAN) In, IR In
ENVIRONMENTAL CONDITIONS
Operating Humidity Range
10% to 80%
Operating Temperature Range
32°F to 104°F / 0°C to 40°C
SOFTWARE COMPATIBILITY
Control and Monitoring Software
SuperSign Control/Control+
Content Management Software
SuperSign CMS
KEY FEATURES
Yes
Yes
Internal Memory 8GB (System 4GB + Available 3.6GB), Built-in Wi-Fi, Temperature Sensor, Auto Brightness Sensor, Current Sensor, Embedded CMS (USB Auto Playback, Local Contents Scheduling, Group Manager), Image Customization, Failover, Content Sync (RS232C, Local Network), Screen Share, Play via URL, OSD Rotation, Content Rotation, PIP/PBP(4), Tile Mode Setting (Max 15x15), Setting Data Cloning, Firmware Update by Network, SNMP 1.4, ISM Mode, Crestron Connected1, Cisco Compatibility 2, Beacon, HDMI-CEC 3, SI Server Setting, webRTC
SOUND
Speaker
-
WARRANTY
Limited Warranty
3-Year Limited Warranty
MEDIA PLAYER COMPATIBILITY
OPS Type Compatible
No
POWER
Power Consumption (Typ./Max)
420W/560W
Power Type
Built-In Power
Power Supply
100-240V~, 50/60Hz
Smart Energy Saving
294W
STANDARD CERTIFICATIONS
Safety
CB / NRTL
ErP
Yes(EU Only)
EMC
FCC Class "A"/CE/KC
PANEL
Lifetime (Typ.)
50,000 Hrs
Panel Technology
IPS
Aspect Ratio
16:9
Panel Size
98"
Brightness
500 nits
Surface Treatment (Haze)
Haze 1%
Viewing Angle (H x V)
178°/178°
Resolution
3840 x 2160 (UHD)
Orientation
Landscape & Portrait
Contrast Ratio
Fri Feb 23 04:01:00 KST 1900
Response Time
8ms (G to G)
Operation Hours
24 Hrs
ACCESSORIES
Basic
Remote Controller, Power Cord, QSG, IR/Light Sensor Receiver, DP Cable (1.8M), Regulation Book, Phone to RS232C Gender, EYE-BOLT
Optional
Speaker (SP-2200)
All image simulations are for illustration purposes only.
