55” IPS UHD Multi Touch Screen Digital Display with webOS 4.1 Smart Signage Platform, Anti-shatter Glass, Conformal Coating & Embedded Group Manager
$4,667.00
55TC3CG-H
55” IPS UHD Multi Touch Screen Digital Display with webOS 4.1 Smart Signage Platform, Anti-shatter Glass, Conformal Coating & Embedded Group Manager
$4,667.00
Key Features
All Specs
- IPS Display with wide viewing angles
- Multi Touch Screen (Up to 40 points)
- webOS 4.1 Smart Signage Platform
- Anti-shatter Glass & Conformal Coating
- SuperSign CMS, Control/Control+
Select Quantity
Max 5 units when checking out as guest. To purchase more than 5 units, please sign in to your LG Business Account
Upgrade your business with LG. Sign up for discounts, higher purchase limits, and more.
Warranty Info
This product comes with standard manufacturer's warranty. Extended Care Plans are available. see here for details
Review your selections
Selection Total
Compare
3 Year Limited Warranty
Buy with confidence knowing your product is backed by a 3 year limited warranty.
Free Delivery
Enjoy free delivery on your business orders.
Free Returns
Shop with confidence. Free returns within 14 days of delivery.
Features and Specs
Engage your Audience
The 55TC3CG-H offers high touch performance and great color with vivid details that can seen at virtually any angle.
Embedded Group Manager
The embedded content management system allows you to edit and play content, schedule a playlist and even group and control signage via remote control, without need for a separate PC. This makes content management much easier and user-friendly.
Multi Screen Mode
PBP (Picture-By-Picture) and PIP (Picture-In-Picture) enables up to two divided split screens in landscape or portrait display format enabling users to more flexibly allocate space for each content source.
Precise Touch Response
The screen accurately recognizes extremely small touch points and instantly shows a response. This means that SIs can compose GUI icons in a variety of sizes on the 55TC3CG-H and users can fully enjoy their touch experience with no lagging.
Multi Touch with No Dead Zones
Capable of recognizing up to 40 point-touches at once, the screen provides multiple users a smooth and natural sense of touch. Unlike infrared touch screens, the 55TC3CG-H accurately detects touch points even at the corners or edges of the display. This allows a variety of touch-based customer services to be provided throughout the entire screen.
Fewer Scratches & Shatter Proof
Touch screens in public spaces can be scratched in heavy use or even abuse situations. The 55TC3CG-H has an advanced tempered screen coating to minimize scratches. In addition, its anti-shatter glass is designed to minimize harm to the user, even in the event the product being subject to abuse.
Conformal Coating
It can be hard to avoid exposure to environments containing dust, humidity, etc. which may hamper performance over time. The conformal coating on the power board of the helps reduce these risks.
Excellent Picture Quality
LG IPS panel features a wide viewing angle to deliver clear content regardless of where meeting participants are seated. Additionally, UHD resolution allows users to view details even when zooming in on the display, with four times higher definition than Full HD.
Various Sensor Applications
LG webOS smart signage platform easily supports connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc. via USB plug-in. With webOS smart signage, there’s no need to purchase additional software or media players.
Software Features
Gapless Playback
Yes
Picture-by-Picture (PBP)
Yes (4)
Control Manager
Yes
SI Server Setting
Yes
Setting Data Cloning
Yes
Status Mailing
Yes
Auto Set ID
Yes
Scan Inversion
No
Backlight Sync
No
ISM Method
Yes
Group Manager
Yes
Booting Logo Image
Yes
Network Ready
No
RS-232C Sync
Yes
W/B Setting by Grayscale
No
webRTC (Real Time Communication)
Yes
Video Tag
Yes (4)
PM mode
Yes
Picture-in-Picture (PIP)
Yes
Local Network Sync
Yes
Screen Rotation
Yes
Smart Energy Saving
Yes
Tile Mode Setting
Yes (Max. 15 x 15)
External Input Rotation
Yes
No Signal Image
Yes
SNMP
Yes
Brightness Compensation
No
Local Contents Scheduling
Yes
HDMI-CEC
Yes
USB Plug & Play
Yes
OPS Compatibility
OPS Power Built-in
No
OPS Compatible
Yes (Piggyback)
Hospitality Features
Pro:Idiom®
Yes
Wake on LAN
Yes
Electrical
Power Consumption (Max.)
145W
Power Supply
100-240 Vac, 50/60 Hz
Power Consumption (Power Off)
Less than 0.5W
Power Type
Built-in Power
PoE Type
N/A
PoE Power Class
N/A
Power Consumption (Display Power Management - DPM)
Less than 0.5W
Power Consumption (Smart Energy Saving - 70%)
74 W
BTU Heat Generation (Max.)
495 BTU
BTU Heat Generation (Typ.)
358 BTU
Power Consumption (Typ.)
105 W
Mechanical
Bezel Color
Black
Bezel Width
T: 33.5mm, R/L: 33.4 mm, B: 38 mm
Bezel Width (On Bezel)
Not Available
Bezel Width (Off Bezel)
Not Available
Tilt (Face Down)
No
Tilt (Face Up)
No
Weight
78.0 lbs / 34.5 kg
Weight Signage Box
N/A
Weight with Stand
Not Available
Shipping Weight
87.7 lbs / 39.8 kg
Dimensions (W x H x D)
50.3 x 29.6 x 1.8 in / 1276.4 x 751.9 x 44.9 mm
Dimensions with Stand (W x H x D)
Not Available
Dimensions with Pemnut (W x H x D)
N/A
Dimensions Signage Box (W x H x D)
N/A
Shipping Dimensions (W x H x D)
55.5 x 34.6 x 8.1 in / 1410 x 880 x 207 mm
Conformal Coating (Power Board)
Yes
Handle
No
VESA™ Standard Mount Interface
300 x 300 mm
Overlay Touch Compatibility
No
Smart Calibration
No
Power Protection
No
Direct Sunlight
No
Protective Glass
Thickness
No
Degree of Protection
No
Tempered / Chemical Strengthening
No
Anti-Reflective
No
Anti-Reflective Coating
No
Anti-Reflective Film
No
Infrared - Resistance (IR)
No
Shatter-Proof
No
Heat Dissipation
No
Heater
No
Noise Level
No
Audio/Sound
Built-in Speakers
No
Hardware Features
Local Key Operation
Yes
Built-in Microphone
No
Built-in Camera
No
Pixel Sensor
No
Temperature Sensor
Yes
Auto Brightness Sensor
Yes
Built-in Cooling Fan
No
Acceleration (Gyro) Sensor
No
Current Sensor
No
BLU Sensor
No
Power Indicator
No
Proximity Sensor
No
Humidity Sensor
No
Features
Crestron Certified Compatibility
Yes
Beacon
No
Play Via URL
Yes
Cisco Certified Compatibility
Yes
Failover
Yes
System
Operating System (OS)
webOS™ 4.1
Processor
No
Graphics
No
Storage
No
Internal Memory
8 GB (System 4 GB + Available 3.6 GB) (eMMC)
Touch Panel
Available Object Size for Touch
Greater than 6 mm
Response Time (PC Win10, Education Mode)
≤100 ms
Touch Response Time (G to G)
N/A
Writing Height
No
Accuracy (Typ.)
2 mm
Interface
USB 2.0
Active Pen Interface
No
Multi Touch Point (Max.)
Max 40 Points
Protection Glass Transmission
83%
Protective Glass Thickness
3.2T (Anti-Glare)
Operating System Support
Win 8.1 / 10, Linux (Kernel v3.0 above)
Connectivity
HDMI In
Yes (x2) HDCP 2.2/1.4
IR In (3.5 mm)
Yes (x1)
IR In (3.5 mm)
Yes
DVI-D In
No
RGB In
No
Audio In (3.5 mm)
No
DisplayPort In
Yes (x1) HDCP 2.2/1.3
RS-232C In (3.5 mm 4-pin)
Yes (x1)
RS-232C In (D-sub 9-pin)
No
RJ45 (LAN) In
Yes (x1)
USB Type-A In
Yes (x2) USB 2.0
USB Type-C In
No
Power In (DC From External PWR Box)
No
Power Loop In
No
HDMI Out
No
DisplayPort Out
Yes (x1), input HDMI 1 / 2 / DP / OPS
Audio Out (3.5 mm)
Yes (x1)
Touch USB
Yes (x1) USB 2.0
IR Out
No
RJ45 (LAN) Out
No
RS-232C Out (3.5 mm)
Yes (x1)
RS-232C Out (D-sub 9-pin)
No
Power Loop Out
No
External Speaker Out (3.5 mm)
Yes (6 ohm)
Bluetooth
No
Daisy Chain
Yes (input HDMI, DP / Output DP)
Built-in Wi-Fi
No
Warranty & Other
Assembled In
Korea
Warranty
3 Year Limited
Onscreen Display Languages
Arabic, Chinese (Original), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Italian, Japanese, Korean, Norwegian, Portuguese (Brazil), Portuguese (Europe), Russian, Simplified Chinese, Spanish, Swedish, Türkçe
Optional Accessories
Wall bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSF), SP-5200
UPC
1 95174 00538 5
Basic Accessories (included)
Power Cord 1.55 M*1, USB Cable (Type A-Type B) 1.8 M*1, HDMI Cable 3 M*1, User Manual, QSG, Remote Controller (include battery 2ea), RS232C cable (3.5mm), IR Receiver , Magnet Sheet (3ea)
Environmental Conditions
Operation Humidity
10% to 80%
Operation Temperature (Portrait)
N/A
Operation Temperature
32°F to 104°F / 0°C to 40°C
Regulatory & Certifications
UL Certification
No
U.S. ePEAT (Environmental)
No
FCC (Regulatory)
EMC Class A
IP Rating (Solid / Liquid Ingress)
No
TAA Compliance
No
CE Marking (Regulatory)
Yes
ISTA6 (Packaging)
No
ERP (Environmental)
Yes
Energy Star (Environmental)
Yes
Smart Features
Screen Share
No
LG Software Compatible
SuperSign™ CMS
Yes
SuperSign™ Media Editor
No
SuperSign™ Control+
Yes
SuperSign™ WB
No
SuperSign™ Cloud
No
Mobile CMS
Yes
ConnectedCare™
Yes
Panel
Screen Size (Inches)
55"
Panel Technology
IPS
Backlight Type
Edge
Aspect Ratio
16:9
Native Resolution
3840 x 2160 (UHD)
Refresh Rate
60 Hz
Brightness (Typ.)
350 nits
Brightness (Max.)
Not Available
Brightness (Min.)
Not Available
Contrast Ratio
1000:1
Dynamic Contrast Ratio
500000:1
Color Gamut
NTSC 72%
Color Depth (Number of Colors)
10 bit, 1.07 Billion Colors
Viewing Angle (H x V)
178° x 178°
Response Time (G to G)
9 ms
Moving Picture Response Time
N/A
Surface Treatment (Haze)
28%
Surface Treatment (Anti Glare)
No
Surface Treatment (Hard Coating)
No
Reflectance (Typ.)
N/A
Operation Hours (Hours per Day / Days per Week)
24/7
Lifetime
Up to 50,000 Hrs
Orientation
Portrait / Landscape
Transparency
No
QWP (Quarter Wave Plate)
No
¹ This feature may have a restriction depending on the TV models.
