55” SVM5F-H Series 0.44mm EVEN BEZEL FHD IPS Video Wall with Smart Calibration, 500 nits Brightness and webOS Smart Signage Platform
DISCONTINUED
55SVM5F-H
55” SVM5F-H Series 0.44mm EVEN BEZEL FHD IPS Video Wall with Smart Calibration, 500 nits Brightness and webOS Smart Signage Platform
Key Features
All Specs
- Brightness(Typ.) : 500 nits
- Bezel : 0.44 mm (Even)
- Depth : 86.5 mm
- Surface Treatment: Haze 28%
- Interface : HDMI(2)/ DP/ DVI-D/ USB 2.0/ RS232C/ RJ45/ Audio/ IR
- Smart Calibration
Compare
Specs & Resources
ACCESSORY
Basic
Remote Controller, Power Cord, RS232C Cable, LAN Cable, DP Cable, IR Receiver, Guide Bracket, Screws, Manual
Optional
Wall Mount ( Landscape : WM-L640V, Portrait : WM-P640V), OPS Kit (KT-OPSF)
CONNECTIVITY
Input
HDMI (2), DP, DVI-D, Audio, USB 2.0
Output
DP, Audio
External Control
RS232C In/Out, RJ45 (LAN) In/Out, IR In
POWER CONSUMPTION
Smart Energy Saving
105W
Typ. / Max.
200W / 250W
CERTIFICATION
EMC
FCC Class "A" / CE / KC
Safety
CB / NRTL
ErP
Yes (EU Only)
SOFTWARE COMPATIBILITY
Control and Monitoring Software
SuperSign Control / Control+
Content Management Software
SuperSign CMS
MEDIA PLAYER COMPATIBILITY
OPS type compatible
Yes (Piggyback)
ENVIRONMENT CONDITIONS
Operation Humidity
10 % to 80 %
Operation Temperature
32°F to 104°F / 0°C to 40°C
MECHANICAL SPECIFICATION
Bezel Width
0.44 mm (Even)
Packed Weight
52 lbs. / 23.6 kg
VESA™ Standard Mount Interface
600 x 400 mm
Weight (Head)
37 lbs. / 16.8 kg
Bezel Color
Black
Handle
Yes
Monitor Dimension (W x H x D)
47.7” x 26.8” x 3.4” / 1,210.51 x 681.22 x 86.5 mm
Carton Dimensions (W x H x D)
53.3” x 33.7” x 10.4” / 1,353 x 855 x 263 mm
POWER
Power Type
Built-In Power
Power Supply
100-240 V~, 50/60 Hz
PANEL
Surface Treatment
Haze 28%
Panel Technology
IPS
Aspect Ratio
16:9
Native Resolution
1,920 x 1,080 (FHD)
Viewing Angle (H x V)
178 x 178
Dynamic CR
500,000 : 1 (The luminosity ratio of Full Black/Full White color on video input condition.)
Orientation
Portrait & Landscape
Contrast Ratio
1,100:1
Response Time
8 ms (G to G)
Screen Size
55"
Operation Hours
24Hrs
Life Time (Typ.)
60,000 Hrs
Brightness (Typ., nits)
500
All image simulations are for illustration purposes only.
