55” class - Versatile Signage with a User-friendly Smart Platform
DISCONTINUED
55SM5KE
55” class - Versatile Signage with a User-friendly Smart Platform
Key Features
All Specs
- User-Friendly Smart Platform
- Content Display and Management
- Powerful Wireless Capabilities
- Reliable Operation
- Value-added Offerings
- Industrial Design
Compare
Specs & Resources
KEY FEATURES
Yes
Internal Memory 8GB (System 4GB, Available 3.6GB), Built-in Wi-Fi, Temperature Sensor, Auto Brightness Sensor, Current Sensor, webOS 4.0, Embedded CMS, Fail Over, Image Customization, PIP/PBP(2), Screen Share, Video Tag (2), Play via URL, Gapless Playback, Tile Mode Setting (Up to 15x15), Setting Data Cloning, Firmware Update by Network, SNMP (Ver. 1.4), Control Manager, Crestron Connected®*, Extron IP Link, Smart Energy Saving, Beacon, HDMI-CEC (2)**, Built-in Speaker (10W+10W)
PHYSICAL SPECIFICATIONS
Weight (Head + Stand)
45.9 lbs / 20.8 kg
Carton Dimensions (W x H x D)
52.4” x 31.8” x 6.7” / 1,330 x 807 x 170 mm
Monitor Dimension (W x H x D)
48.7” x 28.4” x 2.1” / 1,238 x 714.9 x 54 mm
Bezel Color
Black
Weight (Head)
38.6 lbs / 17.5 kg
Bezel Width
11.9 mm (T/R/L), 18 mm (B)
VESA TM Standard Mount Interface
300mm x 300mm
Monitor w/opt. Stand Dimensions (W x H x D)
48.7” x 30.4” x 8.6” / 1,238m x 773.4 x 219.6 mm
Packed Weight
47.8 lbs / 21.7 kg
CONNECTIVITY
Input
HDMI (3), DP, DVI-D, Audio, USB 3.0
Output
DP (SST), Audio (Off/Fixed/Variable)
External Control
RS232C In/out, RJ45 In, IR Receiver In
ENVIRONMENTAL CONDITIONS
Operating Humidity Range
10 % to 80 %
Operating Temperature Range
0°C to 40°C / 32°F to 104°F
WARRANTY
Limited Warranty
3-Year Limited Warranty
SOFTWARE COMPATIBILITY
Control and Monitoring Software
SuperSign Control+/Control
Content Management Software
SuperSign CMS
MEDIA PLAYER COMPATIBILITY
External Media Player Attatchable
Yes
OPS Type Compatible
Yes
POWER
Power Consumption (Typ./Max)
100 W (TBD) / 115 W
Power Type
100-240V~, 50/60Hz
Power Supply
Built-In Power
Power Consumption (Smart Energy Saving)
70 W (TBD)
STANDARD CERTIFICATIONS
Safety
IEC 60950-1 / EN 60950-1 / UL 60950-1
EMC
FCC Class "A" / CE / KCC
PANEL
Lifetime (Typ.)
50,000 Hrs
Panel Technology
IPS
Aspect Ratio
16 : 9
Brightness
450 nits
Native Resolution
1,920 x 1,080 (FHD)
Surface Treatment (Haze)
Hard Coating (3H), Anti-glare Treatment of the Front Polarizer (Haze 1% (Typ.))
Viewing Angle (H x V)
178°/178°
Orientation
Landscape & Portrait
Contrast Ratio
1,100:1
Response Time
12 ms (G to G BW), 9.0 ms (WOT)
Screen Size
55"
Operation Hours
24 Hrs
ACCESSORIES
Basic
Remote Controller (2ea Batteries Included), Power Cord, QSG, HDMI Cable, Regulation Book, Phone to RS232C Gender, Memory Cover
Optional
Stand (ST-492T), Media Player, Wall Bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSA), HDBaseT (EB-B100), Touch Overlay (KT-T49E)
All image simulations are for illustration purposes only.
