SM5D Series
DISCONTINUED
49SM5D-B
SM5D Series
Key Features
All Specs
- Brightness(Typ.): 450 cd/m²
- Bezel: Top/Left/Right 11.9 mm (Bottom 18.0 mm)
- Depth: 38.6 mm
- Orientation: Landscape & Portrait mode
- Interface: HDMI, DVI, DP, RGB, RJ45, IR, RS232C, USB
Compare
Specs & Resources
Accessory
Basic
Remote Controller(include battery 2ea), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, Memory cover
Optional
Speaker(SP-5000), Stand(ST-492T), Pixel sensor(KT-SP0), Media player, Wall bracket(LSW350B), VESA Adapter(AM-B330S), OPS Kit(KT-OPSA), HD Base T(EB-B100), Touch overlay (KT-T490)
CONNECTIVITY
Input
HDMI(2), DP, DVI-D, RGB, Audio
Output
DP, Audio, External Speaker
External Control
RS232C in/out, RJ in, IR Receiver, Pixel Sensor, USB 3.0
Power Consumption
Typ.
85W
Smart Energy Saving
60W
ENVIRONMENTAL CONDITIONS
Operation Humidity
10 % to 80 %
Operation Temperature
0°C to 40°C
SOFTWARE COMPATIBILITY
Content Management Software
SuperSign Premium
Control and Monitoring Software
SuperSign Link
MEDIA PLAYER COMPATIBILITY
External Media Player Attatchable
Yes (MP500/MP700)
OPS Type Compatible
Yes
POWER
Power Supply
100-240 V~, 50/60 Hz
Power Type
Built-In Power
Standard (Certification)
Safety
UL / cUL / CB / TUV / KC
EMC
FCC Class "A" / CE / KCC
PANEL
Resolution
1,920 x 1,080 (FHD)
Screen Size
49"
Brightness(Typ.,cd/m²)
450
Physical Specification
Bezel Width
11.9 mm (T/R/L), 18 mm (B)
Monitor Dimension (W x H x D)
1102.2mm x 638.5mm x 38.6mm
Weight (Head)
14.1kg
VESA™ Standard Mount Interface
300 x 300
All image simulations are for illustration purposes only.
