43" class (42.5" / 1,079.5mm diagonal) Smart Platform with a Powerful Embedded System-on-Chip

Name: 43" class (42.5" / 1,079.5mm diagonal) Smart Platform with a Powerful Embedded System-on-Chip
Brand: LG Electronics
SKU: 43SM5B
Availability: Discontinued

DISCONTINUED

43SM5B

43" class (42.5" / 1,079.5mm diagonal) Smart Platform with a Powerful Embedded System-on-Chip

Key Features

All Specs

QUAD CORE SOC
CONFORMAL COATING (PROTECTION IN HARSH ENVIRONMENTS)
BUILT-IN WI-FI
OPS(OPEN PLUGGABLE SPECIFICATION) KIT OPTION

Compare

Specs & Resources

Collapse All

INPUT

RS232C

Yes (1)

HDTV Formats

HDMI : 720p, 1080i, 1080p

Analog RGB

Yes (1)

External Control

RJ45

Digital HDMI

HDMI1.4b/HDCP2.2

IR Cap Receiver

Yes (1)

Pixel Sensor

Yes (1)

Digital DVI-D

HDCP2.2

Digital DP

DP1.2a

Audio In

RGB/DVI

USB3.0

Yes (1)

SD Card (Full Size)

Yes (1)

AUDIO

Sound Mode

Standard, News, Music, Cinema, Sport, Game

Audio Power

20W (10W x 2) for External Speaker

Clear Voice II

Yes

Balance

Yes

Virtual Surround

Yes

Equalizer

Yes

OUTPUT

External Control

RS232C

External Speaker Out

Yes (L/R), 6 ohm

DP Out

SST/DP1.2a

Audio Out

Yes

WARRANTY

Warranty

3-Year Limited Warranty Parts/Labor/Backlight | Extended warranty options are also available

ENVIRONMENT CONDITIONS

Operation Temperature

0 °C to 40 °C

Operation Humidity

10 % to 80 %

UPC

7 19192 19663 6

POWER

Power Supply

110 ~ 240V, 50/60Hz, Normal (Typical) 102W, Stand-by: 0.5W

Power Type

Built-In Power

Power off

0.5W

DPM

0.7W

Power Consumption Typ.

120W

SPECIAL FEATURES

USB Cloning

Logo image download, Sent to USB, Receive from USB

Lock Mode

USB

Tile Mode

Up to 15x15

ISM Method

Normal, White Wash, Color Wash, User image, Scheduling

DPM Select

Yes

Energy Saving

Auto, Minimum, Medium, Maxium, Screen off

Source Selection

RGB, HDMI, DVI-D, DP, OPS, USB, SD Card

Time

Clock, On/Off Timer, Auto Off, Automatic Standby

Input Label

PC/DTV

Temperature Sensor

Yes

File Play with USB

Yes

Internal Memory

8GB (System 4GB + Available 4GB)

Cooling FAN

Brightness / Contrast / Backlight

Yes

Position / Size

Yes

Auto Config / Phase

Yes

Advanced

Dynamic Contrast, Dynamic Color, Color Gamut, Skin Color, Sky Color, Grass Color, Gamma

Natural Mode @ Tile Mode

Yes

Firmware Update (LAN)

Yes

Digital Audio Input

Yes

Power on Delay

0~255

OSD Portrait Mode

0, 90

intelligent Auto

Yes

Password Change

Yes

Set ID Setup

Manual, Auto

Configuration Setup

USB auto Playback

Fail Over

USB, SDcard, RGB, DP, OPS, DVI, HDMI, Internal Memory

SuperSign Server Setup

Signage name, Server IP setting, Server IP Status

SuperSign-w lite

Yes

SuperSign-c

Yes

Language

English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek

Calibration mode

Yes

Power on Status

Standby, Power, LST

Wi-Fi

802.11n combo built-in

Key Operation

IR, Local

Wake On LAN

Yes

Content Scheduling

USB, Internal memory, SD Card

PM Mode

Yes

Savings Time

Yes

Image Diagnosis

Yes

External Media Player Attachable

Yes (MP500/MP700)

Auto Brightness Cap Sensor

Yes

Contents Rotation

0,90

Sync Mode

Time sync, Content sync

Local Time Auto Setting

Yes

OPS PC Power Control

Sync On, Sync On/Off, Disable

Check Screen

Yes

STANDARD (CERTIFICATION)

Safety

UL / cUL / CB / TUV / KC

EMC

FCC Class "A" / CE / KCC

ErP / Energy Star

Yes / Yes, ENERGY STAR® Qualified

EPEAT Gold

Yes

PANEL

Contrast Ratio

1,300:1

Response Time

12ms (G to G)

Dynamic Contrast Ratio

4,000,000:1

Brightness

450cd/m2

Screen Size

43" class (42.5"/1079.5mm diagonal)

Panel Technology

IPS

Aspect Ratio

16 : 9

Native Resolution

1920 x 1080 (FHD)

Viewing Angle (H x V)

178°/178°

Orientation

Portrait & Landscape

Color Depth

16.7 Million

Pixels (H x V x 3)

6,220,800

Color Gamut

68%

Life time (Typ.)

50,000 Hrs

Recommended Use

24hrs/7 days

ACCESSORIES

Basic

Remote Controller(include battery 2ea), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, Memory cover

Optional

Speaker(SP-5000), Stand(ST-652T), Pixel sensor(KT-SP0), Media player, OPS Kit(KT-OPSA), HD Base T(EB-B100)

CABINET

Bezel Color

Black

VESA™ Compatible

11.8” (300mm x 300mm)

Weight

45.4lbs

Bezel Width

11.9mm (T/R/L), 18mm (B)

(W x H x D)

38.2”x22.2”x1.5” (969.6mm x 563.9mm x 38.6mm)

Carton

41.4”x25.6”x4.8” (1052mm x 650mm x 123mm)

Weight (Carton)

37.7lbs

INPUT

RS232C

Yes (1)

HDTV Formats

HDMI : 720p, 1080i, 1080p

Analog RGB

Yes (1)

External Control

RJ45

Digital HDMI

HDMI1.4b/HDCP2.2

IR Cap Receiver

Yes (1)

Pixel Sensor

Yes (1)

Digital DVI-D

HDCP2.2

Digital DP

DP1.2a

Audio In

RGB/DVI

USB3.0

Yes (1)

SD Card (Full Size)

Yes (1)

AUDIO

Sound Mode

Standard, News, Music, Cinema, Sport, Game

Audio Power

20W (10W x 2) for External Speaker

Clear Voice II

Yes

Balance

Yes

Virtual Surround

Yes

Equalizer

Yes

OUTPUT

External Control

RS232C

External Speaker Out

Yes (L/R), 6 ohm

DP Out

SST/DP1.2a

Audio Out

Yes

WARRANTY

Warranty

3-Year Limited Warranty Parts/Labor/Backlight | Extended warranty options are also available

ENVIRONMENT CONDITIONS

Operation Temperature

0 °C to 40 °C

Operation Humidity

10 % to 80 %

UPC

7 19192 19663 6

POWER

Power Supply

110 ~ 240V, 50/60Hz, Normal (Typical) 102W, Stand-by: 0.5W

Power Type

Built-In Power

Power off

0.5W

DPM

0.7W

Power Consumption Typ.

120W

SPECIAL FEATURES

USB Cloning

Logo image download, Sent to USB, Receive from USB

Lock Mode

USB

Tile Mode

Up to 15x15

ISM Method

Normal, White Wash, Color Wash, User image, Scheduling

DPM Select

Yes

Energy Saving

Auto, Minimum, Medium, Maxium, Screen off

Source Selection

RGB, HDMI, DVI-D, DP, OPS, USB, SD Card

Time

Clock, On/Off Timer, Auto Off, Automatic Standby

Input Label

PC/DTV

Temperature Sensor

Yes

File Play with USB

Yes

Internal Memory

8GB (System 4GB + Available 4GB)

Cooling FAN

Brightness / Contrast / Backlight

Yes

Position / Size

Yes

Auto Config / Phase

Yes

Advanced

Dynamic Contrast, Dynamic Color, Color Gamut, Skin Color, Sky Color, Grass Color, Gamma

Natural Mode @ Tile Mode

Yes

Firmware Update (LAN)

Yes

Digital Audio Input

Yes

Power on Delay

0~255

OSD Portrait Mode

0, 90

intelligent Auto

Yes

Password Change

Yes

Set ID Setup

Manual, Auto

Configuration Setup

USB auto Playback

Fail Over

USB, SDcard, RGB, DP, OPS, DVI, HDMI, Internal Memory

SuperSign Server Setup

Signage name, Server IP setting, Server IP Status

SuperSign-w lite

Yes

SuperSign-c

Yes

Language

Calibration mode

Yes

Power on Status

Standby, Power, LST

Wi-Fi

802.11n combo built-in

Key Operation

IR, Local

Wake On LAN

Yes

Content Scheduling

USB, Internal memory, SD Card

PM Mode

Yes

Savings Time

Yes

Image Diagnosis

Yes

External Media Player Attachable

Yes (MP500/MP700)

Auto Brightness Cap Sensor

Yes

Contents Rotation

0,90

Sync Mode

Time sync, Content sync

Local Time Auto Setting

Yes

OPS PC Power Control

Sync On, Sync On/Off, Disable

Check Screen

Yes

STANDARD (CERTIFICATION)

Safety

UL / cUL / CB / TUV / KC

EMC

FCC Class "A" / CE / KCC

ErP / Energy Star

Yes / Yes, ENERGY STAR® Qualified

EPEAT Gold

Yes

PANEL

Contrast Ratio

1,300:1

Response Time

12ms (G to G)

Dynamic Contrast Ratio

4,000,000:1

Brightness

450cd/m2

Screen Size

43" class (42.5"/1079.5mm diagonal)

Panel Technology

IPS

Aspect Ratio

16 : 9

Native Resolution

1920 x 1080 (FHD)

Viewing Angle (H x V)

178°/178°

Orientation

Portrait & Landscape

Color Depth

16.7 Million

Pixels (H x V x 3)

6,220,800

Color Gamut

68%

Life time (Typ.)

50,000 Hrs

Recommended Use

24hrs/7 days

ACCESSORIES

Basic

Remote Controller(include battery 2ea), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, Memory cover

Optional

Speaker(SP-5000), Stand(ST-652T), Pixel sensor(KT-SP0), Media player, OPS Kit(KT-OPSA), HD Base T(EB-B100)

CABINET

Bezel Color

Black

VESA™ Compatible

11.8” (300mm x 300mm)

Weight

45.4lbs

Bezel Width

11.9mm (T/R/L), 18mm (B)

(W x H x D)

38.2”x22.2”x1.5” (969.6mm x 563.9mm x 38.6mm)

Carton

41.4”x25.6”x4.8” (1052mm x 650mm x 123mm)

Weight (Carton)

37.7lbs
