86" UH7N-M Series UHD Signage with webOS™ 6.0, 700 nits Brightness, Conformal Coating, Built-in Speakers & WiFi, SuperSign™ compatible
$5,800.00
NEW
86UH7N-M
86" UH7N-M Series UHD Signage with webOS™ 6.0, 700 nits Brightness, Conformal Coating, Built-in Speakers & WiFi, SuperSign™ compatible
$5,800.00
Key Features
All Specs
- UHD Resolution (3,840 x 2,160) with 700 nits Brightness and 25% Haze
- webOS™ 6.0 & compatible LG SuperSign™ content management software
- Built-in WiFi & Speaker
- Conformal Coating to help protect from dust and humidity
- Lifetime up to 50,000 hours
Select Quantity
Max 5 units when checking out as guest. To purchase more than 5 units, please sign in to your LG Business Account
Upgrade your business with LG. Sign up for discounts, higher purchase limits, and more.
Warranty Info
This product comes with standard manufacturer's warranty. Extended Care Plans are available. see here for details
Review your selections
Selection Total
Compare
3 Year Limited Warranty
Buy with confidence knowing your product is backed by a 3 year limited warranty.
Free Delivery
Enjoy free delivery on your business orders.
Free Returns
Shop with confidence. Free returns within 14 days of delivery.
Features and Specs
Eye-catching large screen
Capture attention with a large screen. The UH7N-M series supports 120Hz, enabling smooth content operation.
High Brightness
The UH7N-M display, with a great brightness of 700 nits, clearly delivers content even in bright stores.
High resolution display
UH7N-M offers a resolution that is four times higher than FHD, satisfying customers visually. Additionally, the anti-glare coating on the screen reduces screen reflection in bright lighting environments, increasing visibility and legibility, providing customers with a comfortable screen.
Versatile operations with multi-USB
With support for two USB ports, UH7N-M offers versatile usage options. Operating content on the screen while simultaneously using other connected devices is possible. This makes simple tasks convenient, such as downloading PPT files from external storage devices while using a mouse or keyboard during a meeting.
Convenient webOS platform
The UH7N-M is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, enabling easy connection with external sensors and webOS partner apps to create an SI-friendly environment.
Durability that provides reliability
Optimized for business environments, the UH7N-M is guarded against the potential impact of salt, dust, iron powder and humidity through the implementation of conformal coating on the power board. Also, its customer-centric features, such as IP5x, 30-degree tilting and Shock Monitoring, provide both reliability and satisfaction.
Supersign compatible
SuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
Software Features
Gapless Playback
Yes
Picture-by-Picture (PBP)
Yes (4)
Control Manager
Yes
SI Server Setting
Yes
Setting Data Cloning
Yes
Status Mailing
Yes
Auto Set ID
Yes
Scan Inversion
No
Backlight Sync
No
ISM Method
Yes
Group Manager
Yes
Booting Logo Image
Yes
Network Ready
Yes
RS-232C Sync
Yes
W/B Setting by Grayscale
No
webRTC (Real Time Communication)
Yes
Video Tag
Yes (4)
PM mode
Yes
Picture-in-Picture (PIP)
Yes
Local Network Sync
Yes
Screen Rotation
Yes
Smart Energy Saving
Yes
Tile Mode Setting
Yes (Max. 15 x 15)
External Input Rotation
Yes
No Signal Image
Yes
SNMP
Yes
Brightness Compensation
No
Local Contents Scheduling
Yes
HDMI-CEC
Yes
USB Plug & Play
Yes
OPS Compatibility
OPS Power Built-in
No
OPS Compatible
No
Hospitality Features
Pro:Idiom®
Yes
Wake on LAN
Yes
Electrical
Power Consumption (Max.)
Not Available
Power Supply
AC 100-240V~, 50/60 Hz
Power Consumption (Power Off)
0.5W
Power Type
Built-in Power
PoE Type
No
PoE Power Class
No
Power Consumption (Display Power Management - DPM)
0.5W
Power Consumption (Smart Energy Saving - 70%)
144W
BTU Heat Generation (Max.)
1,013 BTU
BTU Heat Generation (Typ.)
699 BTU
Power Consumption (Typ.)
205W
Mechanical
Bezel Color
Black
Bezel Width
.52 in / 13.4 mm
Bezel Width (On Bezel)
Not Available
Bezel Width (Off Bezel)
Not Available
Tilt (Face Down)
No
Tilt (Face Up)
No
Weight
116.84 lbs / 53.0 kg
Weight Signage Box
Not Available
Weight with Stand
Not Available
Shipping Weight
147.04 lbs / 66.7 kg
Dimensions (W x H x D)
75.93 x 43.29 x 1.16 in / 1,928.8 x 1,099.8 x 29.7 mm
Dimensions with Stand (W x H x D)
Not Available
Dimensions with Pemnut (W x H x D)
Not Available
Dimensions Signage Box (W x H x D)
Not Available
Shipping Dimensions (W x H x D)
82.67 x 49.21 x 9.96 in / 2,100 x 1,250 x 253 mm
Conformal Coating (Power Board)
Yes (Partial)
Handle
Yes
VESA™ Standard Mount Interface
600 x 400 mm
Overlay Touch Compatibility
No
Smart Calibration
No
Power Protection
No
Direct Sunlight
No
Protective Glass
Thickness
No
Degree of Protection
No
Tempered / Chemical Strengthening
No
Anti-Reflective
No
Anti-Reflective Coating
No
Anti-Reflective Film
No
Infrared - Resistance (IR)
No
Shatter-Proof
No
Heat Dissipation
No
Heater
No
Noise Level
No
Audio/Sound
Built-in Speakers
Yes (x2) 10W
Hardware Features
Local Key Operation
Yes
Built-in Microphone
No
Built-in Camera
No
Pixel Sensor
No
Temperature Sensor
Yes
Auto Brightness Sensor
Yes
Built-in Cooling Fan
No
Acceleration (Gyro) Sensor
Yes
Current Sensor
No
BLU Sensor
No
Power Indicator
No
Proximity Sensor
No
Humidity Sensor
No
Features
Crestron Certified Compatibility
Yes
Beacon
Yes
Play Via URL
Yes
Cisco Certified Compatibility
Yes
Failover
Yes
System
Operating System (OS)
webOS™ 6.0
Processor
Not Available
Graphics
No
Storage
No
Internal Memory
16 GB
Touch Panel
Available Object Size for Touch
No
Response Time (PC Win10, Education Mode)
No
Touch Response Time (G to G)
No
Writing Height
No
Accuracy (Typ.)
No
Interface
No
Active Pen Interface
No
Multi Touch Point (Max.)
No
Protection Glass Transmission
No
Protective Glass Thickness
No
Operating System Support
No
Connectivity
HDMI In
Yes (x2) HDCP 2.2/1.4
IR In (3.5 mm)
Yes (x1)
DVI-D In
No
RGB In
No
Audio In (3.5 mm)
No
DisplayPort In
Yes (x1) (USB-C (DP Alternate mode) shared HDCP 2.2/1.3)
RS-232C In (3.5 mm 4-pin)
Yes (x1)
RS-232C In (D-sub 9-pin)
No
RJ45 (LAN) In
Yes (x1)
USB Type-A In
Yes (x2) USB 2.0
USB Type-C In
Yes (x1) USB 2.0 without PD function
Power In (DC From External PWR Box)
No
Power Loop In
No
HDMI Out
No
DisplayPort Out
No
Audio Out (3.5 mm)
Yes
Touch USB
No
IR Out
No
RJ45 (LAN) Out
No
RS-232C Out (3.5 mm)
Yes (x1)
RS-232C Out (D-sub 9-pin)
No
Power Loop Out
No
External Speaker Out (3.5 mm)
No
Bluetooth
Yes
Daisy Chain
No
Built-in Wi-Fi
Yes
Warranty & Other
Assembled In
Mexico
Warranty
3 Year Limited
Onscreen Display Languages
Arabic, Chinese (Original), Czech, Danish, Dutch, English, Finnish, French, German, Italian, Japanese, Korean, Norwegian, Portuguese (Brazil), Portuguese (Europe), Russian, Simplified Chinese, Spanish, Swedish, Türkçe
Optional Accessories
Wall Mount
UPC
195174097441
Basic Accessories (included)
Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(6EA), Cable Holder(7Pin/1EA)
Environmental Conditions
Operation Humidity
10% to 80%
Operation Temperature (Portrait)
No
Operation Temperature
32°F to 104°F / 0°C to 40°C
Regulatory & Certifications
UL Certification
No
U.S. ePEAT (Environmental)
Yes
FCC (Regulatory)
EMC Class B
IP Rating (Solid / Liquid Ingress)
No
TAA Compliance
No
CE Marking (Regulatory)
No
ISTA6 (Packaging)
No
ERP (Environmental)
No
Energy Star (Environmental)
Yes
Smart Features
Screen Share
Yes
LG Software Compatible
SuperSign™ CMS
Yes
SuperSign™ Media Editor
No
SuperSign™ Control+
Yes
SuperSign™ WB
Yes
SuperSign™ Cloud
Yes
Mobile CMS
Yes
ConnectedCare™
Yes
Panel
Screen Size (Inches)
86"
Panel Technology
ADS
Backlight Type
Edge
Aspect Ratio
16:9
Native Resolution
3840 x 2160 (UHD)
Refresh Rate
120 Hz
Brightness (Typ.)
700 nits
Brightness (Max.)
Not Available
Brightness (Min.)
Not Available
Contrast Ratio
1200:1
Dynamic Contrast Ratio
1000000:1
Color Gamut
BT709 95%
Color Depth (Number of Colors)
1.07 Billion Colors, 8 bit + FRC
Viewing Angle (H x V)
178° x 178°
Response Time (G to G)
8 ms
Moving Picture Response Time
N/A
Surface Treatment (Haze)
25%
Surface Treatment (Anti Glare)
No
Surface Treatment (Hard Coating)
No
Reflectance (Typ.)
No
Operation Hours (Hours per Day / Days per Week)
24/7
Lifetime
Up to 50,000 Hrs
Orientation
Portrait / Landscape
Transparency
No
QWP (Quarter Wave Plate)
No
